Configuration Tool Settings Configuration Tool
26 IFI-WS Installation and Operation Manual – P/N LS10050-000JC-E:A 12/11/2014
3.3.3 Configuration Tool Layout
Figure 3.1 Configuration Tool Layout
Screen Feature Description
Network Configuration Allows an Administrator to add or delete monitored networks to the system configuration.
Screen Objects Allows an Administrator to create and place informational objects on a graphics screen.
User Editor Allows an Administrator to set workstation user passwords and privileges.
Monitoring Profiles
Allow the Administrator to select which nodes are monitored by a workstation. Refer to
3.3.4, "Monitoring Profiles" for additional information.
Launch Database Editor Allows the Administrator to edit the workstation database in a spreadsheet format.
Login
Allows a user to log in to the Intelligent Fire Integrator system. The user can also log out
of the system and log in as another user.
Output Appliances Allows the user to configure the optional output devices.
Colors and Sounds
This section of the configuration tool allows the users to configure custom colors and
sounds for each event type. Refer to 3.3.5, "Color and Sound Configuration" for
additional information.
System Options
Allows the Administrator to select options as to how the workstation interface will operate.
Refer to 3.3.7, "System Options" for additional information.
Exit Click the icon to exit the configuration tool.
