Data Management System Explorer Searches
64 IFI-WS Installation and Operation Manual – P/N LS10050-000JC-E:A 12/11/2014
6.2.2 Header and Row Display Options
6.2.2.1 Header Options
The options listed in Table 6.3 can be accessed by right-clicking the column headings in the main body of the History
Manager window. These options organize the information in the database columns for easier viewing.
6.2.2.2 Row Filter Options
The filter options listed in Table 6.4 can be accessed by right-clicking any row in the main body of the History
Manager window.
6.3 System Explorer Searches
The System Explorer can conduct a generic text search for system devices as follows:
1. Click View > System. The System Explorer window opens.
2. Enter the search text.
3. Click Search. The results appear in the pane on the right.
4. Click OK to close the System Explorer window.
Table 6.3 History Manager Header Options
Option Description
Right-click on a header to display the following options:
Hide Column Tem po ra ri ly h id es t he s el ec te d data co lu mn . Th e column its el f is no t de le te d, o nl y hi dd en .
Select Columns to Show Opens a dialog box that allows the user to select the columns that are displayed.
Show All Columns Removes all previously applied column data filters so that all columns display.
Resize Column Resizes the width of the selected column such that any hidden text is displayed.
Resize All Columns Resizes the width of all displayed columns such that any hidden text is displayed.
Left-click on a header to do the following:
Sort Ascending/Descending Toggles between sorting the column data in ascending or descending order (numeric or
alphabetical).
Table 6.4 History Manager Row Options
Option Description
Filter By Selection Allows the Administrator to display all records according to the event and column that was
right-clicked on.
Filter Excluding Selection Allows the Administrator to exclude displaying all records according to the event and the
column that was right-clicked on.
Filter For Displays a dialog box which allows the Administrator to filter for a specific word or phrase
using keywords and/or the wild card character (%).
Clear All Filters Allows the Administrator to return the History Manager window to the factory default filters.
Once this option has been chosen, all filters are lost unless they where saved using the "Save
Current Query" command.
Show If Greater Than Or Equal To Only displays when time-related data in a row is selected.Allows event filtering by the data in
the Received Time Local column. Only events occurring at the same time and after the
selected event are displayed.
Show If Less Than Or Equal To Only displays when time-related data in a row is selected. Allows event filtering by the data in
the Received Time Local column. Only events occurring at the same time and before the
selected event are displayed.
