Workstation Settings Workstation Settings
41IFI-WS Installation and Operation Manual – P/N LS10050-000JC-E:A 12/11/2014
4.2.5 Pager/Modem Tab
The Pager/Modem tab allows the user to configure the optional paging capabilities of the workstation. These settings
match the settings required for the specific pager. Settings are described in Table 4.6.
Pager notifications are only intended to be transmitted to a limited number of staff for maintenance and system status
purposes. This feature is approved by UL as supplementary.
Table 4.6 Pager/Modem Tab Settings
Setting Possible Settings Description
Buttons:
Add Pager Click to display a pager name dialog box. Enter a unique pager
name and click Yes. The pager name is displayed in the pagers
list.
Delete Pager Highlight a pager name in the list and click to delete it.
Pager List: Click the fields below the headings to enter/modify text or select options from a drop-down list.
Pager Text Field Automatically populates the pager name when a pager is added.
Phone Text Field Enter the pager phone number.
PIN Text Field Enter the pager PIN number.
Enabled/Disabled Enabled Enable the pager selected in the pager list field.
Disabled Disable the pager selected in the pager list field.
All Day Yes Send the event message whenever it occurs.
No Send the event message at configured start and stop times.
Start Time 12 AM to 11 PM in
Hourly Increments
Activates only when “All Day>No” setting is selected. Select the
times from the drop-down list.
Stop Time
Monitoring Default Use the system default monitoring profile.
User-defined
Monitoring Profiles
Select a user-defined monitoring profile from the drop-down list.
Refer to 3.4, "Adding to an Existing Network".
Output Default Use the system default output format.
User-defined Output
Format
Select a user-defined output format from the drop-down list.
Refer to 4.2.7, "Output Tab".
Sample Output: Displays a sample of the event message that will be sent to the selected pager using the format
configured above.
Modem: Displays settings for the connected modem.
Dialing Delay (Sec.) 10 to 30 seconds The time the modem waits before dialing the pager phone
number after the event occurs. (Default is 10 seconds)
Retry Delay (Sec.) 10 to 30 seconds The time the modem waits before re-dialing the pager phone
number. (Default is 10 seconds)
Number of Retries 0 to 3 The number of times the modem tries to send the message if it
fails. (Default is 2)
Time Out (Sec.) 45 to 300 seconds The maximum time the modem will spend trying to contact the
pager. (Default is 90 seconds)
