Key Upgrade Utility Data Management
65IFI-WS Installation and Operation Manual – P/N LS10050-000JC-E:A 12/11/2014
6.4 Key Upgrade Utility
6.4.1 Overview
Every workstation is shipped with an internal USB Hardlock key. This key is programmed to allow features of the
network monitoring system to function on that workstation. A Hardlock key upgrade is required when a new feature
is desired. You must acquire an upgrade code from Technical Services to update the key.
6.4.2 Upgrade Procedure
Upgrade the USB Hardlock key as follows:
1. Shut down the workstation software application.
2. Select Start >Facilities Monitoring >Key Upgrade Utility. The Key Upgrade Utility window displays.
3. Type the code into the Upgrade Code field.
4. Click on the Perform Upgrade button. Fields on the window update to reflect the upgrade code.
5. Click Done to complete the upgrade and close the window.
6.4.3 Key Upgrade Utility Field Descriptions
Refer to the following table for descriptions of the fields in the Key Upgrade Utility:
Table 6.5 Upgrade Utility Fields
Field Description
Installation Name This is typically a default site name. It is not recommended, but the name can be changed by
typing a new name into the field.
Registered This is typically a default site name. It is not recommended, but the name can be changed by
typing a new entry into the field.
Node License Shows how many node licenses are included with the current key configuration.
Serial # Displays the serial number of the Hardlock key (different from the authorization code).
