Workstation Settings Workstation Settings
40 IFI-WS Installation and Operation Manual – P/N LS10050-000JC-E:A 12/11/2014
4.2.3 User Features Tab
4.2.4 Event Printer Tab
The Event Printer tab allows the user to enable or disable the optional printer. An event printer is not required for
UL 864 operations. A default output format and monitoring profile are preconfigured for a local event printer. It is
only necessary to enable the printer in Windows. The local event printer must be named “Local Event Printer”
through Windows. Consult Windows information for details about naming the printer. To modify the printer
configuration, a user-definable monitoring profile must be selected along with a user-definable output format. A
sample event will be displayed using the selected output format. Settings are described in Table 4.5.
Table 4.4 User Features Settings
Setting Possible Settings Description Comments
Unacked Event Alarm Configuration:
This feature is used to automatically activate a user-defined macro if an alarm is present in the new event list for more than the
configured amount of time.
Use Unacked Event
Supervision
True Automatic Unacked Alarm Operation enabled.
False Automatic Unacked Alarm Operation disabled.
Unacked Event
Timeout
(3-60 Minutes)
3 - 60 Time in minutes before the user-defined macro is
executed.
Macro Activated on
Alarm
Macro name Select a macro from the list.
None Do not activate a macro.
Security:
Inactivity Timeout
(0-20) minutes
1-20 Length in minutes of no activity after which a user will be
automatically logged out.
Must be enabled for
UL 2572
compliance.
0Do not automatically log out a user.
User Responses: 8 user-defined
responses.
Enter text that will be stored in history as responses to
events. These are displayed when a user right-clicks on an
icon in the graphics screen.
Table 4.5 Event Printer Tab Settings
Setting Possible Settings Description
Event Printer:
The event printer settings are available only if a Windows printer is connected to the workstation. Click the
fields below the headings to display the options.
Enabled/Disabled Enabled Enable the connected event printer.
Disabled Do not enable the connected event printer.
Monitoring Profile Default Use the system default monitoring profile.
User-defined
Monitoring Profiles
Select a user-defined profile from the drop-down list. Refer to
3.4, "Adding to an Existing Network".
Output Format Default Use the system default output format.
User-defined Output
Format
Select an output format from the drop-down list. Refer to
4.2.7, "Output Tab".
Sample Output:
Displays a sample of the output that will be printed using the settings selected above.
