Operation Auto-creation of Screens, Nodes, and Points
58 IFI-WS Installation and Operation Manual – P/N LS10050-000JC-E:A 12/11/2014
• Advise - A condition that is an administrative event, internal to the Intelligent Fire Integrator system. This is
not a life-safety or security event, but an internal warning of a condition that may need attention, such as the
history file reaching 100,000 entries.
• Other - Other event types such as disabled points on the system.
5.4 Auto-creation of Screens, Nodes, and Points
5.4.1 Overview
The auto-creation process of the workstation software application accomplishes the following:
•Creates a parent screen for the gateway (1), a child screen for the node (2), and a child screen under that (3) for
the points for that node in a navigation tree format (see Figure 5.8).
•Places up to 64 point icons on a workstation screen before it creates the next screen.
Figure 5.8 Example of Autocreated Navigation Tree
1
2
3
