Connections Hardware Configuration
21IFI-WS Installation and Operation Manual – P/N LS10050-000JC-E:A 12/11/2014
10 USB 1 USB 2.0
Type A
Connector
2
•Line impedance 90 ohm ±15%
•Max distance 40 meters
•Power limited
•Supervised
Keyboard or Mouse
11 USB 0 USB 2.0
Type A
Connector
2
•Line impedance 90 ohm ±15%
•Max distance 40 meters
•Power limited
•Supervised
Keyboard or Mouse
12 LAN 1 RJ45 2
•Line impedance 100 ohm
•Max distance 328 ft. (100 m)
•Power limited
•Supervised - Except for ground faults
(See Figure 2.2)
13 LAN 2 RJ45 2 Used only on stand-alone workstations (See Figure 2.3)
14 Line In 3.5 mm Audio Input
15 Mic 3.5 mm Microphone
16 Speaker
(Line Out)
3.5 mm Audio Output
17 J7 Digital I/O Not Used
Not
Shown
USB USB 2.0
Type A
Connector on
Front of PC
2 Maintenance Use Only
Table 2.2 Connection Specifications (Continued)
Item
Reference
Designator
Description
Circuit
Class
Specifications Connection
