Overview System Architecture

69IFI-WS Installation and Operation Manual – P/N LS10050-000JC-E:A 12/11/2014

Figure 7.3 System with Redundant Gateway Example

Protected Premises Unit

NFN Network

Workstation

* Ethernet Hub (TCP/IP)

UL 864 Listed Switch

Redundant Gateway

Other Technologies

LAN/WAN/Internet/Intranet

(Dedicated Only)

* Ethernet Hub (TCP/IP)

UL 864 Listed Switch)

* Ethernet Hub (TCP/IP)

UL 864 Listed Switch

Embedded Gateway

NFN Network

Workstation acting as a Proprietary

Receiving Unit with redundant

gateways. System is not UL-listed

for control in this configuration.
