Trouble
Condition
Trouble
Level 1
Description Trouble Types
Trouble
Level 2
Notification
Level 3
Battery Trouble 02 The system has detected a battery
trouble condition.
Call for service.
Low Battery 01 n/a
No Battery 02
n/a
Low Battery
High-current
O/P
04 Module 1-4
No Battery
High-current
O/P
05 Module 1-4
Low Battery
1A Power Sup-
ply
07 Module 1-4
No Battery
1A Power Sup-
ply
08 Power sup-
ply 1-4
Low Battery
Bus Repeater
10 Repeater
1-8
No Battery
Bus Repeater
11 Repeater
1-8
Low Battery 1
3A Power Sup-
ply
13 Power Sup-
ply
1-4
Low Battery 2
3A Power Sup-
ply
14 Power Sup-
ply
1-4
No Battery 1
3A Power Sup-
ply
15 Power Sup-
ply
1-4
No Battery 2
3A Power Sup-
ply
16 Power Sup-
ply
1-4
