Trouble
Condition
Trouble
Level 1
Description Trouble Types
Trouble
Level 2
Notification
Level 3
Bus Voltage 03 A module has detected a low
voltage on its Corbus red terminal.
HSM2HOST 01 n/a
Keypad 02 Keypad 1-
16
Zone Expander 04 Zone
expander
1-15
1A Power Sup-
ply
05 Power
Module 1-4
High-current
Output
06 Output
Module 1-4
System Area 07 n/a
Output
Expander
08 Module 1-
16
Audio Module 09 n/a
8 I/O Module 10 Module 1-
16
Bus Repeater 11 Repeater
1-8
Bus Fault
Bus Repeater
12 Repeater
1-8
3A Power Sup-
ply
13 Power Sup-
ply 1-4
AC Troubles 04 The system is experiencing loss of
power.
Call for service.
If the building and/or neighbourhood
has lost electrical power, the system
will continue to operate on battery
for several hours.
Zone 01 Zone label
or 001-128
Keypad 02 Keypad 1-
16
Siren 03 Siren 1-16
Repeater 04 Repeater
1-8
Power Supply 05 Power sup-
ply 1-4
High-current
Output
06 Output
terminal 1-
4
System Area 07 n/a
Bus Repeater 08 Repeater
1-8
3A Power Sup-
ply
09 Power Sup-
ply 1-4
