Johnson Controls YORK OPTIVIEW CONTROL CENTER User Manual

JOHNSON CONTROLS
137
APPENDIX B - PROGRAMMABLE SETPOINT VALUES
FORM 160.10-O1
ISSUE DATE: 4/27/2018
B
SETUP SCREEN
SETPOINT
ACCESS
LEVEL
MINIMUM
VALUE
MAXIMUM
VALUE
DEFAULT
Set Date Operator 16/01/1963 01/01/4000 01/01/1999
Set Time Operator
12:00 AM or
00:00
11:59 PM or
23:59
12:00 AM or
00:00
Clock Operator Disable Enable Enable
12/24 Hr (Clock Mode) Operator 12 Hr Mode 24 Hr Mode 12 Hr Mode
SCHEDULE SCREEN (SETUP SUBSCREEN)
SETPOINT
ACCESS
LEVEL
MINIMUM
VALUE
MAXIMUM
VALUE
DEFAULT
Schedule Operator Disabled Enabled Disabled
Schedule Data: Sunday through Saturday, Start Time
and Stop Time, Standard Week and six Exception
Weeks
Operator
12:00 AM or
00:00
11:59 PM or
23:59
12:00 AM or
00:00
Repeat Sunday Operator No Yes No
Repeat Exceptions Operator No Yes No
USER SCREEN (SETUP SUBSCREEN)
SETPOINT
ACCESS
LEVEL
MINIMUM
VALUE
MAXIMUM
VALUE
DEFAULT
Data Display Mode Operator English or Metric English
User ID (ID 1 through 4) Service 1 9999 1
User Password (ID 1 through 4) Service 0 9999 0
User Level (ID 1 through 4) Service 0 - View, 1 - Operator, 2 - Service 0
COMMS SCREEN (SETUP SUBSCREEN)
SETPOINT
ACCESS
LEVEL
MINIMUM
VALUE
MAXIMUM
VALUE
DEFAULT
Chiller ID Operator 0 255 0
Baud Rate (Printer Setup and COM 2) Operator
1200, 2400, 4800, 9600, 19200,
38400, 57600
19200
Data Bits (Printer Setup and COM 2) Operator 5 Bits, 6 Bits, 7 Bits, 8 Bits 8 BIts
Parity (Printer Setup) Operator None, Odd, Even None
Parity (COM 2) Operator None, Odd, Even Odd
Stop Bits (Printer Setup and COM 2) Operator 1 Bit 2 Bits 1 Bit
TABLE 13 - PROGRAMMABLE SETPOINT VALUES (CONT’D)
