FORM 160.75-N1
ISSUE DATE: 04/15/2019
SECTION 1 - INTRODUCTION
LD29123
Nozzle with flange
150 lb and 300 lb closures
1
2
3
4
5
6
7
Nozzle without flanges
(Lines 4 in. through 12 in.)
Nozzle without flanges
(Lines 14 in. through 24 in.)
8
9
8
9
ITEM DESCRIPTION
1 Tag Warning Dennison 8E
2 Gauge Press 2 Dia 0-30
3 Tag GlvSt Wire Speed
4 Bush Pipe 3/4 - 14 NPTE X
5 Valve, Transducer 1/4 NPTE X
6 Flange Cover
7 Gasket
8 Victaulic Coupling
9 Sealing Cap
FIGURE 3 - LONG TERM STORAGE - TUBE SIDE
