JOHNSON CONTROLS
15
SECTION 1 - INTRODUCTION
FORM 160.75-N1
ISSUE DATE: 04/15/2019
1
ALL DIMENSIONS ARE IN INCHES (MM)
FIGURE 6 - SPRING ISOLATORS
UNIT WEIGHT
35,010 Lbs UP TO 58,349 Lbs
(15,881 Kgs UP TO 26,467 Kgs)
SHELL
6-SPRING ISOLATORS
END
SHEET
CAP
SCREW
ADJUSTING
BOLT
5 1/2"
(140)
LD19579
UNIT WEIGHT
58,350 Lbs. UP TO 89,340 Lbs
(26,468 Kgs UP TO 40,525 Kgs)
SHELL
9-SPRING ISOLATORS
END
SHEET
CAP
SCREW
ADJUSTING
BOLT
9”
(229)
9”
(229)
6-1/4"
(159)
LD19419
SHELL
4-SPRING ISOLATORS
END
SHEET
CAP
SCREW
ADJUSTING
BOLT
1”
(25)
5 1/2”
(140)
1 3/8”
(35)
6”
(152)
6”
(152)
LD19573
SHELL
4-SPRING ISOLATORS
END
SHEET
CAP
SCREW
ADJUSTING
BOLT
7”
(178)
7”
(178)
1”
(25)
5 1/2”
(140)
1 3/8”
(35)
LD19572
UNIT WEIGHT
10,000 to 19,563
(4,536 to 8,873 Kgs)
UNIT WEIGHT
19,564 Lbs UP TO 35,009 Lbs
(8,874 Kgs UP TO 15,880 Kgs)
