JOHNSON CONTROLS
40
FORM 160.75-N1
ISSUE DATE: 04/15/2019
SECTION 2 - INSTALLATION
FIGURE 27 - DIMENSIONS – EVAPORATOR MARINE WATERBOXES
EVAPORATOR MARINE WATERBOX NOZZLE ARRANGEMENTS - FT-IN (MM)
LD07175a
LD07175a
MARINE WATERBOXES – 150 PSI ROUND
EVAP
SHELL
CODE
NOZZLE PIPE SIZE IN (MM)
NUMBER OF PASSES
1-PASS 2-PASS 3-PASS
1 2 3 C P
5
P
5
Q
5
R P
5
Q
5
R
A
8"
(203)
6"
(152)
4"
(101)
1'-3 1/2"
(394)
3'-7"
(1092)
3'-7"
(1092)
0-11"
(279)
1'-3 1/4"
(387)
3'-7"
(1092)
0'-11"
(279)
1'-3 1/4"
(387)
C,D
10"
(254)
8"
(203)
6"
(152)
1'-5 1/2"
(445)
3'-11"
(1194)
3'-11"
(1194)
0'-10"
(254)
1'-6 1/2"
(470)
3'-11"
(1194)
0'-10"
(254)
1'-6 1/2"
(470)
E,F
14"
(356)
10"
(254)
8"
(203)
1'-7 1/2"
(495)
4'-3"
(1295)
4'-3"
(1295)
0'-11"
(279)
1'-9 1/2"
(546)
4'-3"
(1295)
0'-11"
(279)
1'-9 1/2"
(546)
G,H
14"
(356)
10"
(254)
8"
(203)
2'-0"
(610)
4'-5 1/2"
(1359)
4'-5 1/2"
(1359)
1'-0 1/2"
(318)
1'-11 1/2"
(597)
4'-5 1/2"
(1359)
0'-11"
(279)
1'-9 7/8"
(556)
I,J,K,L
16"
(406)
12"
(305)
10"
(254)
2'-1 1/4"
(641)
5'-0 3/8"
(1,534)
5'-0 3/8"
(1,534)
0'-10 1/2"
(267)
2'-2 1/2"
(673)
5'-0 3/8"
(1,534)
0'-10 1/2"
(267)
2'-2 1/2"
(673)
M,N
18"
(457)
14"
(356)
12"
(305)
2'-4 1/2"
(724)
5'-8 1/2"
(1,740)
5'-8 1/2"
(1,740)
1'-2"
(356)
2'-2 1/2"
(673)
5'-8 1/2"
(1,740)
1'-2"
(356)
2'-4 3/4"
(730)
P, Q
18"
(457)
14"
(356)
12"
(305)
2'-5 1/2"
(749)
6'-0 1/8"
(1,832)
6'-0 1/8"
(1,832)
1'-3"
(381)
2'-6 1/2"
(775)
6'-0 1/8"
(1,832)
1'-3"
(381)
2'-6 1/2"
(775)
QT, QV
20"
(508)
16"
(406)
12"
(305)
2'-5 1/2"
(749)
6'-0 1/8"
(1,832)
6'-0 1/8"
(1,832)
1'-4 1/2"
(419)
2'-6 1/2"
(775)
6'-0 1/8"
(1,832)
1'-4 1/2"
(419)
2'-6 1/2"
(775)
R,S
20"
(508)
18"
(457)
14"
(356)
2'-8"
(813)
6'-5 7/8"
(1,978)
6'-5 7/8"
(1,978)
1'-3 3/4"
(400)
3'-0 1/8"
(918)
6'-5 7/8"
(1,978)
1'-3 3/4"
(400)
3'-0 1/8"
(918)
W
20"
(508)
18"
(457)
14"
(356)
2'-8"
(813)
6'-5 7/8"
(1,978)
6'-5 7/8"
(1,978)
1'-3 3/4"
(400)
3'-0 1/8"
(918)
6'-5 7/8"
(1,978)
1'-3 3/4"
(400)
3'-0 1/8"
(918)
X,Z
20"
(508)
18"
(457)
14"
(356)
2'-11 1/2"
(902)
6'-11 1/2"
(2121)
6'-11 1/2"
(2121)
2'-1 3/4"
(654)
3'-2 1/8"
(968)
6'-11 1/2"
(2121)
1'-8 1/4"
(514)
3'-2 1/8"
(968)
