Johnson Controls YORK YK Series Installation Instructions

JOHNSON CONTROLS
31
SECTION 2 - INSTALLATION
FORM 160.75-N1
ISSUE DATE: 04/15/2019
2
FIGURE 18 - DIMENSIONS – EVAPORATOR COMPACT WATERBOXES
EVAPORATOR COMPACT WATERBOXES - FT-IN (MM)
F
F
F
F
F
G
LD07619
See Notes on page 25.
ONE PASS EVAPORATORS, SHELL CODES
DIMENSIONS A C,D E,F G,H I,J,K,L M,N P, Q R,S,W X,Z
F
1'-2 1/4"
(362)
1'-3"
(381)
1'-3 1/2"
(394)
1'-3 3/4"
(400)
1'-5 1/2"
(445)
1'-11 5/8"
(600)
1'-11 5/8"
(600)
2'-0 5/8"
(625)
2'-1 3/4"
(654)
TWO PASS EVAPORATORS, SHELL CODES
DIMENSIONS A C,D E,F G,H I,J,K,L M,N P, Q R,S,W X,Z
F
1'-2 1/4"
(362)
1'-3"
(381)
1'-3 1/2"
(394)
1'-3 3/4"
(400)
1'-5 1/2"
(445)
1'-11 5/8"
(600)
1'-11 5/8"
(600)
2'-0 5/8"
(625)
2'-1 3/4"
(654)
G
0'-6 1/2"
(165)
0'-7"
(178)
0'-7 1/2"
(191)
0'-7 3/4"
(197)
0'-9 1/2"
(241)
1'-3 5/8"
(397)
1'-3 5/8"
(397)
1'-4 3/4"
(425)
1'-5 3/4"
(451)
THREE PASS EVAPORATORS, SHELL CODES
DIMENSIONS A C,D E,F G,H I,J,K,L M,N P, Q R,S,W X,Z
F
1'-2 1/4"
(362)
1'-3"
(381)
1'-3 1/2"
(394)
1'-3 3/4"
(400)
1'-5 1/2"
(445)
1'-11 5/8"
(600)
1'-11 5/8"
(600)
2'-0 5/8"
(625)
2'-1 3/4"
(654)
