Johnson Controls YORK YK Series Installation Instructions

JOHNSON CONTROLS
44
FORM 160.75-N1
ISSUE DATE: 04/15/2019
SECTION 2 - INSTALLATION
TABLE 2 - APPROXIMATE UNIT WEIGHT INCLUDING MOTOR FOR FLOODED EVAPORATOR UNITS -
LB (KG)
SHELLS COMPRESSOR
SHIPPING
WEIGHT
LBS (KGS)
OPERATING WEIGHT
LBS (KGS)
ESTIMATE
REFRIGERANT
CHARGE LBS (KGS)
A-A Q3 13,100 (5,942) 15,000 (6,804) 810 (367)
C-B Q4 18,023 (8,175) 22,323 (10,126) 1,525 (692)
C-C Q3, Q4 14,920 (6,768) 17,940 (8,138) 1,240 (562)
C-C Q5 15,330 (6,954) 18,350 (8,324) 1,240 (562)
D-D Q3, Q4 17,215 (7,809) 21,100 (9,571) 1,680 (762)
D-D Q5 17,625 (7,995) 21,510 (9,757) 1,680 (762)
E-E Q3, Q4 17,950 (8,142) 22,160 (10,052) 1,710 (776)
E-E Q5,Q6,Q7,P7 18,360 (8,328) 22,570 (10,238) 1,710 (776)
E-I Q7 23,567 (10,690) 29,384 (13,328) 1,805 (819)
F-F Q5,Q6,Q7,P7 18,720 (8,491) 23,880 (10,832) 2,175 (987)
G-E P8 20,300 (9,208) 24,200 (10,977) 1,990 (903)
H-F P8,P9 23,100 (10,478) 28,000 (12,701) 2,610 (1,184)
J-J P8,P9 24,000 (10,886) 29,100 (13,200) 2,550 (1,157)
L-L P8,P9 27,400 (12,429) 33,900 (15,377) 3,165 (1,436)
K-K H9 28,530 (12,941) 36,000 (16,329) 2,925 (1,327)
K-K K1 31,100 (14,107) 36,200 (16,420) 3,248 (1,473)
K-O H9 34,483 (15,641) 44,776 (20,310) 3,260 (1,479)
M-M H9 34,200(15,513) 43,600 (19,777) 3,665 (1,662)
M-M K1,K2 38,300 (17,373) 47,100 (21,364) 3,665 (1,662)
M-U K2 45,178 (20,493) 58,017 (26,316) 3,540 (1,606)
N-N K1,K2 28,530 (18,549) 50,800 (23,043) 4,225 (1,916)
N-N K3 48,000 (21,773) 54,100 (24,540) 4,225 (1,916)
P-P K1,K2 41,500 (18,824) 51,900 (23,542) 3,855 (1,749)
Q-Q K1,K2 45,300 (20,548) 56,800 (25,764) 4,255 (1,930)
Q-Q K3 46,000 (20,865) 60,200 (27,307) 4,255 (1,930)
R-R K3 52,800 (23,950) 70,300 (31,888) 4,660 (2,114)
R-R K4 53,000 (24,041) 70,600 (32,034) 4,785 (2,170)
S-S K4 59,000 (26,672) 76,300 (34,609) 4,940 (2,241)
S-V K4 60,100 (27,261) 81,300 (36,877) 5,500 (2,495)
X-T K4 59,200 (26,853) 80,000 (36,288) 5,125 (2,325)
X-X K4 66,000 (29,937) 87,000 (39,463) 5,625 (2,551)
W-W K7 79,500 (36,061) 104,000 (47,174) 6,900 (3,130)
Z-Y K7 95,300 (43,196) 123,015 (55,799) 6,555 (2,973)
Z-Z K7 80,500 (36,515) 105,000 (47,628) 6,275 (2,846)
NOTE: Refrigerant charge quantity and weights will vary based on tube count, conguration, and chiller performance. Use for reference only.
Refer to YORKworks Performance Page or chiller nameplate for actual charge requirement.
