Johnson Controls YORK YK Series Installation Instructions

JOHNSON CONTROLS
41
SECTION 2 - INSTALLATION
FORM 160.75-N1
ISSUE DATE: 04/15/2019
2
FIGURE 28 - DIMENSIONS – CONDENSER MARINE WATERBOXES
LD07178a
MARINE WATER BOXES – 150 PSI ROUND
CONDENSER
SHELL CODE
NOZZLE PIPE SIZE
IN (MM) NUMBER OF
PASSES
1-PASS 2-PASS 3-PASS
1 2 3 D S
5
S
5
T
5
U S
5
T
5
U
A
10"
(254)
6"
(152)
6"
(152)
1'-3"
(381)
3'-11"
(1,194)
3'-11"
(1,194)
1'-8"
(508)
1'-3 3/8"
(391)
3'-11"
(1,194)
1'-8"
(508)
1'-3 3/8"
(391)
C,D
12"
(305)
8"
(203)
6"
(152)
1'-3 1/2"
(394)
4'-3"
(1,295)
4'-3"
(1,295)
1'-8"
(508)
1'-6 1/2"
(470)
4'-3"
(1295)
1'-8"
(508)
1'-6 1/2"
(470)
E,F
14"
(356)
10"
(254)
8"
(203)
1'-5 1/2"
(445)
4'-7"
(1,397)
4'-7"
(1,397)
1'-10"
(559)
1'-9"
(533)
4'-7"
(1,397)
1'-10"
(559)
1'-9"
(533)
J,K,L
16"
(406)
10"
(254)
10"
(254)
1'-8"
(508)
5'-1"
(1,549)
5'-1"
(1,549)
1'-9"
(533)
1'-9 1/2"
(546)
5'-1"
(1,549)
1'-9"
(533)
1'-9 1/2"
(546)
M,N
20"
(508)
14"
(356)
10"
(254)
1'-11"
(584)
5'-9 7/8"
(1,775)
5'-9 7/8"
(1,775)
2'-4"
(711)
2'-1 1/2"
(648)
5'-9 7/8"
(1,775)
2'-4"
(711)
2'-1 1/2"
(648)
P, Q
20"
(508)
16"
(406)
14"
(356)
2'-1 1/4"
(641)
6'-2 3/8"
(1,889)
6'-2 3/8"
(1,889_
2'-4 1/2"
(724)
2'-5 1/2"
(749)
6'-2 3/8"
(1,889)
2'-4 1/2"
(724)
2'-5 1/2"
(749)
R,S
20"
(508)
18"
(457)
14"
(356)
2'-3 1/2"
(699)
6'-7"
(2007)
6'-7"
(2007)
2'-6 1/2"
(775)
2'-8 1/2"
(825)
6'-7"
(2007)
2'-6 1/2"
(775)
2'-8 1/2"
(826)
T,V,W
24"
(610)
18"
(457)
16"
(406)
2'-5 1/2"
(749)
6'-10 1/4"
(2,089)
6'-10 1/4"
(2,089)
2'-6"
(762)
2'-10"
(864)
6'-10 1/4"
(2,089)
2'-6"
(762)
2'-10"
(864)
X,Z
24"
(610)
20"
(508)
16"
(406)
2'-8"
(813)
7'-2"
( 2184)
7'-2"
( 2184)
2'-7 3/4"
( 806)
2'-11 1/2"
(902)
7'-2"
(2184 )
2'-7 3/4"
(806)
2'-11 1/2"
(902)
LD07178a
CONDENSER MARINE WATERBOX NOZZLE ARRANGEMENTS - FT-IN (MM)
