SECTION 2 - INSTALLATION
YK MOD G HEAT RECOVERY COMBINATIONS
COMPRESSOR
CODES
EVAPORATOR
CODES
CONDENSER
CODES
MOTOR CODES
60 HZ 50 HZ
Q4 CP, CQ, CR, CS BV, BW, BX
CF-CT
EF-ET
5CC-5CO
5EC-5EO
Q7 EP, EQ, ER, ES, ET IV, IW, IX
H9 KP, KQ, KR, KS, K2, K3, K4 OW, OX, O7, O8, O9
CN-CA
EN-EA
5CK-5CW
5EK-5EW
K2 MQ, MR, MS, M2, M3, M4 UW, UX, U7, U8, U9
CS-DC
ES-FC
5CN-5DC
5EN-5FB
K7 ZQ, ZR, ZS, Z1, Z2, Z3, Z4 YW, YX, Y7, Y8, Y9 DD-DL 5DD-5DL
YK MOD G HYBRID FALLING FILM COMBINATIONS
COMPRESSOR
CODES
HYBRID
FALLING FILM
EVAPORATOR CODES
CONDENSER
CODES
MOTOR CODES
60 HZ 50 HZ
Q3
AC, AD, A3, A4 AP to AS
CF-CT
EF-ET
5CC-5CO
5EC-5EO
CC to CE, C3 to C5 CP to CS
Q4
CC to CE, C3 to C5 CP to CS
DC to DE, D3 to D5 DP to DS
Q5
CC to CE, C3 to C5 CP to CS
CH-CT
EH-ET
5CE-5CO
5EE-5EO
DC to DE, D3 to D5 DP to DS
Q5, Q6, Q7
EC to EE, E3 to E5 EP to ET
FC to FE, F3 to F5 FQ to FT
P7
EC to EE, E3 to E5 EP to ET
CU-CY
EU-EY
5CP-5CU
5EP-5EU
FC to FE, F3 to F5 FQ to FT
P8, P9
GC to GE, G3 to G5 EV to EX, E3 to E4
CH-CZ
EH-EZ
5CE-5CU
5EE-5EU
HC to HE, H3 to H5 FV to FX, F3 to F4
H9
KC, KD, K8, K9, K0 KP, KQ, KR, KS, K2, K3, K4
CN-CA
EN-EA
5CK-5CW
5EK-5EW
IB, IC, ID, IF, IH, I2, I4, I6, I8 KP, KQ, KR, KS, K2, K3, K4, K5
MB, MD, MF, M5, M7, M8 MP, MQ, MR, MS, M2, M3, M4
K1 IB, IC, ID, IF, IH, I2, I4, I6, I8 KP, KQ, KR, KS, K2, K3, K4, K5
CS-DC
ES-FC
5CN-5DC
5EN-5FB
K1, K2
MB, MD, MF, M5, M7, M8, M9 MP, MQ, MR, MS, M2, M3, M4
NB, ND, NF, N5, N7, N8, N9 NP, NQ, NR, NS, N2, N3, N4
PB, PD, PF, P5, P7, P8 PQ, PR, PS, P2, P3, P4
QB, QD, QF, Q5, Q7, Q8 QQ, QR, QS, Q2, Q3, Q4
K3
NB, ND, NF, N5, N7, N8, N9 NP, NQ, NR, NS, N2, N3, N4
DA-DJ
FA-FD
5DA-5DH
5FA-5FB
QD, QF, QH, Q5, Q7, Q8, Q9 QQ, QR, QS, Q2, Q3, Q4
TABLE 1 - AVAILABLE COMPRESSOR/SHELL/MOTOR COMBINATIONS (CONT'D)
