Table 61: Approximate unit weight including motor for flooded evaporator units - lb (kg)
Shells Compressor Shipping weight lb (kg) Operating weight lb (kg) Estimate refrigerant charge lb (kg)
K-K H9 28,530 (12,941) 36,000 (16,330) 2,925 (1,327)
K-K K1 31,100 (14,107) 36,200 (16,420) 3,248 (1,473)
K-O H9 34,483 (15,641) 44,776 (20,310) 3,260 (1,479)
M-M H9 34,200 (15,513) 43,600 (19,777) 3,665 (1,662)
M-M K1,K2 38,300 (17,373) 47,100 (21,365) 3,665 (1,662)
M-U K2 45,178 (20,493) 58,017 (26,317) 3,540 (1,606)
N-N K1,K2 28,530 (12,941) 50,800 (23,043) 4,225 (1,916)
N-N K3 48,000 (21,773) 54,100 (24,540) 4,225 (1,916)
P-P K1,K2 41,500 (18,824) 51,900 (23,542) 3,855 (1,749)
Q-Q K1,K2 45,300 (20,548) 56,800 (25,764) 4,255 (1,930)
Q-Q K3 46,000 (20,866) 60,200 (27,307) 4,255 (1,930)
R-R K3 52,800 (23,950) 70,300 (31,888) 4,660 (2,114)
R-R K4 53,000 (24,041) 70,600 (32,024) 4,785 (2,170)
S-S K4 59,000 (26,762) 76,300 (34,610) 4,940 (2,241)
S-V K4 60,100 (27,261) 81,300 (36,878) 5,500 (2,495)
X-T K4 59,200 (26,853) 80,000 (36,288) 5,125 (2,325)
X-X K4 66,000 (29,938) 87,000 (39,463) 5,625 (2,552)
W-W K7 79,500 (36,061) 104,000 (47,174) 6,900 (3,130)
Z-Y K7 95,300 (43,228) 123,015 (55,800) 6,555 (2,973)
Z-Z K7 80,500 (36,515) 105,000 (47,628) 6,275 (2,846)
Note: Refrigerant charge quantity and weights vary based on tube count, configuration, and
chiller performance. Use for reference only. Refer to YORKworks Performance Page or chiller
nameplate for actual charge requirement.
Table 62: Approximate unit weight including motor for hybrid falling film evaporator units -
lb (kg)
Shells Compressor Shipping weight lb (kg) Operating weight lb (kg) Estimated refrigerant charge lb
(kg)
A-A Q3 12,850 (5,584) 14,419 (6,540) 695 (315)
C-C Q3, Q4 14,570 (6,609) 16,848 (7,642) 875 (397)
C-C Q5 15,000 (6,804) 17,278 (7,837) 875 (397)
D-D Q4 17,000 (7,711) 20,051 (9,095) 1,180 (535)
D-D Q5 17,410 (7,897) 20,461 (9,281) 1,180 (535)
E-E Q5, Q6, Q7, P7 18,700 (8,482) 21,700 (9,843) 1,120 (508)
F-F Q5, Q6, Q7, P7 19,220 (8,718) 23,142 (10,497) 1,415 (642)
G-E P8, P9 20,640 (9,362) 24,036 (10,903) 1,320 (599)
H-F P8, P9 23,540 (10,678) 28,083 (12,738) 1,775 (805)
I-K H9 28,849 (13,086) 34,078 (15,458) 1,820 (826)
K-K H9 28,850 (13,086) 34,079 (15,458) 1,820 (826)
I-K K1 31,350 (14,220) 35,145 (15,942) 1,820 (826)
M-M K1, K2 34,520 (15,000) 46,055 (20,013) 2,300 (1,043)
N-N K1, K2 41,273 (18,721) 49,605 (22,501) 2,650 (1,202)
N-N K3 48,380 (21,945) 52,905 (23,998) 2,650 (1,202)
P-P K1, K2 41,950 (19029) 51,595 (23,403) 3,100 (1,406)
Q-Q K1, K2 45,800 (20,775) 56,545 (25,649) 3,500 (1,588)
Q-Q K3 46,500 (21,092) 59,945 (27,191) 3,500 (1,588)
Note: Refrigerant charge quantity and weights will vary based on tube count, configuration,
and chiller performance. Use for reference only. Refer to YORKworks Performance Page or chiller
nameplate for actual charge requirement.
Model YK (Style G) Centrifugal Liquid Chiller62
