Add the following evaporator marine waterbox weights to the standard unit weights shown in Table
61 and Table 62
Table 63: Evaporator marine waterbox weights - lb (kgs).
Shipping weight Operating weight
Increase - lb (kg) Increase - lb (kg)
Evaporator
code
1-pass 2-pass 3-pass 1-pass 2-pass 3-pass
A 924
(419)
744
(337)
978
(444)
1,468
(666)
1,288
(584)
1,522
(690)
C,D 1,352
(613)
1,114
(505)
1,480
(671)
2,224
(1,009)
1,986
(901)
2,352
(1,067)
E,F 1,878
(852)
1,260
(572)
2,080
(943)
3,378
(1,532)
2,760
(1,252)
3,580
(1,624)
G,H 1,213
550
1,296
(588)
1,293
(587)
2,655
(1,204)
2,738
(1,242)
2,735
(1,241)
I,J,K,L 1,751
(794)
1,843
(836)
1,856
(842)
3,864
(1,753)
3,956
(1,794)
3,969
(1,800)
M,N 4,290
(1,946)
2,036
(924)
4,140
(1,878)
7,535
(3,418)
3,264
(1,481)
6,300
(2,858)
P,Q 5,982
(2,713)
3,281
(1,488)
5,724
(2,596)
10,854
(4,923)
5,277
(2,394)
9,442
(4,283)
R,S,W 4,804
(2,179)
2,700
(1,225)
4,912
(2,228)
8,522
(3,866)
4,516
(2,048)
8,187
(3,714)
X,Z 7,088
(3,215)
3,660
(1,660)
7,244
(3,286)
11,552
(5,240)
5,507
(2,498)
11,243
(5,100)
The following condenser marine waterbox weights are to be added to the standard unit weights
shown in Table 61 and Table 62
Table 64: Condenser marine waterbox weights - lb (kg).
Shipping weight Operating weight
Increase - lb (kg) Increase - lb (kg)
Condenser code
1-pass 2-pass 3-pass 1-pass 2-pass 3-pass
A
762
(346)
566
(257)
810
(367)
1,274
(578)
1,078
(489)
1,322
(600)
B
1,569
(712)
874
(396)
1,677
(761)
2,113
(958)
1,094
(496)
2,071
(939)
C,D
946
(429)
778
(353)
1,046
(474)
1,692
(767)
1,524
(691)
1,792
(813)
E,F
726
(329)
811
(368)
791
(359)
1,337
(606)
1,722
(781)
1,702
(772)
I
2,066
(937)
1,070
(485)
2,032
(922)
3,017
(1,396)
1,416
(642)
2,738
(1,242)
J,K,L
1,029
(467)
1,167
(529)
1,151
(522)
2,309
(1,047)
2,448
(1,110)
2,431
(1,103)
M,N
2,466
(1,119)
1,330
(603)
2,324
(1,054)
4,863
(2,206)
2,448
(1,110)
4,582
(2,078)
O
2,985
(1,354)
1,443
(655)
2,987
(1,355)
4,435
(2,012)
2,172
(985)
3,979
(1,805)
P,Q
3,700
(1,678)
1,858
(843)
3,752
(1,702)
6,561
(2,976)
3,132
(1,421)
5,991
(2,717)
R,S
3,806
(1,726)
1,946
(883)
3,960
(1,796)
6,657
(3,020)
3,195
(1,449)
6,352
(2,881)
63Model YK (Style G) Centrifugal Liquid Chiller
