The following activation and setup procedure should be used for all JR XP652 systems. Please note that the XF622 and XP642 6 channel systems do
not have the required CCPM software, and therefore cannot be activated by the Horizon Service Center.
Prior to activating the CCPM function, it is first suggested that the data reset function be performed to reset the desired model number to be used
back to the factory default settings.
Caution: Prior to performing the data reset function, it will be necessary to select the desired model number to be used.
A) Model Selection
Press the Mode and Channel keys simultaneously while turning the power switch on to
enter the system mode. Next, press the Channel key until “MDL” (model select)
appears on the screen and choose the desired model number to be used.
B) Data Reset
Press the Mode key until “RST” (data Reset) appears on the screen. Press the + and -
keys simultaneously to reset the current model. A high-pitched beep will indicate that
the reset was successful. Press the Mode and Channel keys simultaneously to exit the
system mode.
C) CCPM Activation
With the power switch still on, press the Mode and Channel keys simultaneously to enter the function mode. Press the Mode key until mix
“CCP” (CCPM mixing) appears on the screen. Press the + or - keys to activate the CCPM function. Mix Cp2 should appear on the screen.
Next, press the Channel key until “MIX CP6” appears on the screen. It will be necessary to change the value of CP2, CP3, and Cp6 (Channel 6,
Aux1) using the - key as shown below.
D) Servo Reversing
Press the Mode key until the servo reversing screen appears on the screen. Next, reverse the elevator (ELE), rudder (RUD) and
pitch (PIT) channels by pressing the Channel key to select the desired channel, and then the + or - keys to set the servo direction.
CCPM SOFTWARE ACTIVATION AND INITIAL ADJUSTMENT
1. JR XP652 SYSTEMS
mdl
1
Indicates Model Select
Indicates Current Model
rst
hhee
Indicates Data Reset
Indicates Model Type
mixCCP
ooff
Indicates CCPM Mixing
Indicates Inhibited
ele
rev
.
norm
rud
rev
.
norm
pit
rev
.
norm
mixCP6
++ 5500
%
Indicates Channel 6 (Aux 1, Right Servos)
Indicates Value Set – 50%
Indicates Channel 3
Indicates
Reversed
Indicates Channel 4
Indicates Reversed
Indicates
Channel 6
Indicates Reversed
To Next Page
