JR XP810-3 User Manual

www.modelflight.com.au – World’s best source of JR products
4
.
1
0 Aileron to Rudder Mixin
g
(
Function Mode
)
, cont.
Indicates the
function being
selected:
↓
Rate
↓
SW
SW OFF appears when the Flap Mixing
is in the middle or lower position
Aileron to Rudder Mixing V alue (± 125%)
Indicates current Mixing Switch acitvated
Press the UP and DN keys
simultaneously to enter/exit
the Function Mode
Press the DN and Select key
s
simultaneously to access th
e
Function Mode List Dis
p
la
y
UP
DN SELECT CH CH CLEAR
To Butterfly Mixing
function
To Flap to Aileron
Mixin
g
function
Function Selection
⌫ Rates ⌫ Switch
A
t rate, press to
increase/decrease
Mixing V
alue (± 125%)
At switch, press to
change switch
selection
Press to return the
Mixing Value to zero or
to return the active
Mixin
g
Switch ON
4
.
1
1 Butte
r
fl
y
Mixin
g
(
Crow
)
(
Function Mode
)
The purpose of this mixing is to allow the spoiler stick (throttle
stick) to activate the main wing’ s trailing edge and activate
brake operation for the glider . T o avoid pitching up when flaps
are deployed, elevator mixing is employed. T wo dif ferent
landing settings are available.
Note that this mixing is also called Spoileron or Crow .
Setting Spoiler Of fset
T o access spoiler to flap mixing, press the CH key until Spoiler
Of fset Setting Function is displayed. Place the spoiler stick in the
low position and memorize the of fset position by pressing the
Clear key . Note that spoiler trim operation af fects this mixing.
In Function Mode, use the UP and DN keys to select Butter fly
Mixing and access by pressing the UP and DN keys
simultaneously .
2
c
h
(
AIL1
)
5
c
h
(
AIL2
)
Settin
g
Mixin
g
V alue
The mixing values can be set to two dif ferent settings by utilizing
the butter fly switch. T o reverse the operating direction, press the
- ke
y
to increase the minus value.
GLID 121
