2
Function Mode
From Normal Display
, press the UP and DN keys simultaneously
to enter the Function Mode. In this mode, by using the UP or DN
keys, the desired functions can be selected. When channel
selection or an additional function change is desired, use the
CH keys or SEL key. For example, Dual Rate Function is selected
and the elevator channel is displayed by pressing the UP key
once; the function is changed to the next mode, Reverse Switch,
but the channel is still displayed as elevator
.
Function Mode Flowchar
t
Therefore, by scrolling through the program, you can adjust
each function related to the elevator channel quickly and easily
.
T
o
Access The Function Mode
1.
Switch the power switch to the ON (upper) position.
2.
Press the UP and DN keys simultaneously
.
3.
Use either the UP or DN keys to scroll through the menu and
access the appropriate function.
Infor
mation per
taining to each function is explained on the page
number listed next to the function name. Functions will appear
on the screen in the same order they are shown on the flow
cha
To Next Page
