2.3 Menu Handling
Menu handling is standardized for all different menu screens and for all different instruments. See Figure 16: Menu
Example on page 24 for an example of the MENU and Table 10: Explanation of On-screen Buttons and Icons on
page 24 for an explanation of the on-screen buttons and icons.
Figure 16: Menu Example
Go to main screen. Touch again to go to MENU.
Go back to the previous screen without saving settings.
Undo the last value change.
Accept and save current settings and applied settings will be saved.
Undo all settings and exit MENU
Scroll between standard settings using the + or – button
Standard settings are divided into several screens. Navigate through these screens
using the < or > button.
Table 10: Explanation of On-screen Buttons and Icons
24 | Operation
