Options Operation
10-4
10.4 Channel selector (NCM-2000)
CAUTION
For channel selectors installed above deck, close the water-resistant cap after use. Rain
and sea breeze could cause connector malfunction. Also do not leave the handset
above deck.
1. TX Lamp
Lights when transmitting.
2. 1W Lamp
Lights when transmitting power is 1W.
3. OCC Lamp
Lights if not having the access right.
4. 25W/1W Switch
Switches transmitting power between 25W and 1W. If pressed and held for two seconds, this unit becomes
to the menu mode. In this mode, select the desired item with the ▲ or ▼ key and press ENT, then perform
the procedure in the table below. When finishing this menu mode, press and hold for two seconds again.
Display Setting Setting Method
S.1 Squelch level Select 00 (open) - 32 with the ▲ or ▼ key, and press ENT.
S.2 PHONE level Select 01 - 99 with the ▲ or ▼ key, and press ENT.
S.3 Channel 16 setting by on-hook Select ON/OFF with the ▲ or ▼ key, and press ENT.
S.4 Hook switch detection function Select ON/OFF with the ▲ or ▼ key, and press ENT.
S.5 Fine brightness
1) Select a brightness level from bright (B.1), medium
(B.2), or dark (B.3) with the ▲ or ▼ key, and press
ENT.
2) Select the fine brightness value (01-10) for the
brightness level selected in 1) with the ▲ or ▼ key,
and press ENT.
S.0 (Ends the menu mode.) -----
1
2
3
4
5
6
8
7
9
10
To Next Page
