5-30
For connecting BAM
When connecting to BAM, please use DATA OUT4/IN4 port.
• Even if the input setting is "OFF", the ACK, ACN and HBT sentence can be received.
Select IEC/OFF for
DATE OUT4/IN4
DATA I/O settings menu
Screen display change exsample for IEC selection
Screen display change exsample for output sentence settings
“VERSION” can not be
selected.
When connecting to BAM, select
“ALERT” and “HBT”.
If “ALERT” is selected, “ALF”,
“ALC”, “ARC” and “AGL” sentences
can be output.
Memo
