JLR-7700 MK2 GPS Navigator
・ To erase the correction value, press the 0 , 0 , 0 , 0 , and ENT keys.
・ Note that it is not necessary to press the N/S or E/W key if the display are correct.
4.4.2.3 Setting the DGPS BEACON
The beacon reception mode for the DGPS receiver can be selected either from automatic or manual mode,
when DGPS receiver is connected.
・ Press the key provided on the right hand side of the DGPS BEACON.
① In case the needs to be automatically selected
・ Press the key to highlight the AUTO.
・ The equipment will automatically select and receive a frequency and baud rate for the beacon station that
is closest to the GPS position measured with the DGPS receiver.
② In case the needs to be manually selected
・ Press the key to highlight the MANUAL. Then, manually enter the frequency and baud rate of the
beacon station that needs to be selected.
Example)
When selecting the beacon station with the frequency of 320.0 kHz and baud rate of 200 BPS.
(1) Press the key provided on the right hand side of the FREQ and set the frequency to 320.0 kHz
by pressing either or key.
(2) Press the key provided on the right hand side of the BPS and set the baud rate to 200 by
pressing either or key.
The value shown under the term RSSI displayed at the bottom of the screen represents the level of the
signals being received from the beacon station.
