JLR-7700 MK2 GPS Navigator
② Entering the bearing and distance from the current position
The equipment accepts direct input of a desired waypoint position with the bearing and distance
from the current position. This function can be used when it is necessary to enter the waypoint on the
radar screen with the bearing and distance to the specified landmark.
Example) Operate as follows to enter 45 degrees and 7.0 nm. Note that the true bearing needs to be
entered in the true bearing display mode, or the magnetic bearing in the magnetic bearing
display mode.
・ Press the key provided on the right hand side of the BRG/DIST, then the 0 , 4 , 5 ,
ENT , 0 , 7 , 0 , and ENT keys. This operation will execute the bearing and distance inputs.
4.5.2 WAYPOINT LIST Screen
4.5.2.1 Copying the Waypoint Data
The waypoint position stored at a given number in the equipment can be copied to another number. This is a
convenient function when it is necessary to edit the destinations stored with the EVENT key or to rearrange the
waypoint numbers for a given route plan.
・ Firstly select a waypoint number that needs to be copied with the or key.
The waypoint number can be easily and quickly located by pressing the GOTO key before the desired
waypoint number input.
・ Press the COPY key after selecting a waypoint that needs to be copied.
・ Enter the waypoint number to be copied to when COPY FROM 003 TO _ _ _ and COPY
messages are displayed.
4.5.2.2 Erasing the Waypoint Data
A registered waypoint data can be erased with the equipment by implementing the following operations.
・ Select a waypoint number that needs to be erased on the WAYPOINT LIST screen.
Select the number with the or key, or GOTO key before waypoint number input.
・ Then, press the CLR and ENT keys to erase the waypoint data.
