JRC JMA-7725-6 - Past Position Display

5.4
5 – 15
5.4.2 Past Position Display
Display the position of a target using the
SUB
MENU
key.
Up to four past position can be displayed. The track mode displays the true or relative track together with the
vector mode.
The relative vector mode displays the relative track of a target.
The true vector mode displays the true track.
Displaying the past position
Procedures
1. Press the
SUB
MENU
key to open the SUB MENU.
2. Press the
5
key to open the ATA #1 menu.
3. Press the
3
key to select "PAST POSITION".
4. Press the
3
key to select "OFF" or "ON".
5. Press the
ENT
key to set the past position.
Setting the past position interval
6. Press the
4
key in the procedure 3 for displaying the past position
to select "PAST POSITION TIME".
7. Press the
4
key several times to select "30SEC", "1MIN", "2MIN" or
"4MIN".
8. Press the
ENT
key to set the past position interval.
Exit
9. Press the
SUB
MENU
key.
