JRC JMA-7725-6 - Adjustment and Setting at Installation; Adjusting Tuning

8
8 – 22
8.5
8.5.2 Adjustment and Setting at Installation
8.5.2.1 Adjusting Tuning
Procedures
1. Set the range at 24nm or more to adjust the [TUNE] control at the center.
2. Press the
SUB
MENU
key to open the SUB MENU.
3. Press the
9
key twice to open the INIT SET #2 menu.
4. Press the
3
key to select "TUNE ADJUSTMENT".
5. Press the
ENT
key to clear the menu and display the radar screen.
“Adjusting TUNE” will be displayed in the lower right corner of the screen.
6. Press the minus (-) side of the
RANGE
key or plus (+) side of the
RANGE
key to make the turning indication of the lower left of the screen the longest
and press the
ENT
key.
Init set #2
1. BEARING ADJUSTMENT
2. RANGE ADJUSTMENT
3. TUNE ADJUSTMENT
4. SETTING OF PRF 23
5. PM ADJUSTMENT
6. DATA INPUT FORMAT
183 JRC 180
7. INITIALIZING GPS MENU (STBY)
8. SETTING DGPS MENU (STBY)
INIT
SET #2
0. PREV
9. NEXT
