2-19
②：Interference rejection (IR) mode switching
The list opens whenever this button is clicked.
Clicking the item in the list, selects the interference rejection mode.
Selecting item is IR Off , IR Low , IR Medium and IR High .
③：Target enhance (ENH) mode switching
The list opens whenever this button is clicked.
Clicking the item in the list, select the target enhance mode.
Selecting item is ENH Off , ENH Level1 , ENH Level2 and ENH Level3.
④：Radar video processing (PROC) mode switching
The list opens whenever this button is clicked.
Clicking the item in the list, selects the radar video processing mode.
Selecting item is 3Scan CORREL , 4Scan CORREL , 5Scan CORREL , Remain and
Peak Hold .
⑤：Function (FUNC) mode switching
The list opens whenever this button is clicked.
Clicking the item in the list, selects the function mode.
Selecting item is FUNC Off , Coast , Deep Sea , Fishnet and Storm .
⑥, ⑦, ⑧,and ⑨：Gain, Sea clutter suppression (Sea), Rain / snow clutter
suppression (Rain), Tune adjustment
Adjust the gain, sea clutter suppression, rain / snow clutter suppression and tune using the track ball.
When the button is clicked on, the adjustment value is shown at the lower-left of the screen. Make
adjustments by control bar. Determine the adjustment by left-clicking Exit button.
When canceling these adjustment value, left-click Cancel button.
⑩, ⑪,and ⑫：Sea clutter suppression (Sea) mode, Rain and snow clutter
suppression (Rain) mode, and Tune mode switching
Use these functions to switch to the manual or automatic mode of sea clutter suppression, rain and snow
clutter suppression, and tune. The bar on the left side indicates the position of the dial.
The mode is switched to MAN (manual) / AUTO (automatic) whenever the button is clicked.
When rain and snow clutter suppression is switched to an automatic mode, sea clutter suppression is
switched to an automatic mode also.
