JUKI DDL-8000A Engineer's Manual

– 3 –
❶
❸
⓴
❹
❾
❷
⓫
⓬
⓲
⓭
󱢾
⓱
⓰
⓳
❿
❺
⓮
❼
⓯
❽
❻
2. Name of each component
❶
Control box
󱢵
Reverse feed lever
❷
Operation Panel
󱢶
Hand wheel
❸
Power switch
󱢷
Take-up lever cover
❹
Thread stand
󱢸
Finger guard
❺
Operation pedal
󱢹
Under cover
❻
LED hand light
󱢺
2nd thread tension
❼
One-touch type reverse feed button
󱢻
Power switch (For CE)
❽
Needle thread presser device
⓳
Pedal sensor
❾
Bobbin winder unit
⓴
USB terminal
󱢳
1st thread tension
󱢾
USB terminal
󱢴
Oil ller port

JUKI DDL-8000A Specifications

General

Stitch Type	Lockstitch
Motor Type	Direct-drive motor
Thread Trimmer	Automatic
Max. Stitch Length	5mm
Needle Bar Stroke	30.7mm
Lift of the Presser Foot	By hand: 5.5mm, By knee: 13mm
Control Panel	Digital
Lubrication	Automatic
