JUKI DDL-8000A Engineer's Manual

– 20 –
Adjustment Procedure Results of Improper Adjustment
1) Method of lubrication
1. SH, SJ type (Specication for minute-quantity lubrication)
Face plate needle
bar lubrication :
Minute-quantity lubrication by the oil wick ❶.
Hook ❷ : Forced lubrication by the plunger pump ❸
Quantity of oil can be adjusted by the hook
oil adjusting screw ❹.
Lubricant can be fed to the oil tank ❺
through the arm lubrication hole ❻.
2. MS type (Specication for semi-dry items)
Face plate needle
bar lubrication : Lubrication by grease sealed in the needle
bar lower metal ❼.
Hook ❷ :
Forced lubrication by the plunger pump
❸
Quantity of oil can be adjusted by the hook
oil adjusting screw
❹
.
Lubricant can be fed to the oil tank
❺
through the arm lubrication hole
❻
.

JUKI DDL-8000A Specifications

General

Stitch Type	Lockstitch
Motor Type	Direct-drive motor
Thread Trimmer	Automatic
Max. Stitch Length	5mm
Needle Bar Stroke	30.7mm
Lift of the Presser Foot	By hand: 5.5mm, By knee: 13mm
Control Panel	Digital
Lubrication	Automatic
