JUKI SC-922 Supplementary Instructions Manual

– 5 –
[ LU-2200 series ]
Please perform Procedures 1) to 4) except LU-22*6N
series (long arm).
LU-22*6N series (long arm) should perform only Pro-
cedure 5).
1) Install panel thread guide
󰿿
to the installing plate
with screw
󱀀
, spring washer
󱀁
and washer
󱀂
supplied as accessories.
5) Install the installing plate with setscrews
󱢴
and
washers
󱢵
.
3) Remove setscrews
󱀇
andatwashers
󱢳
at-
tached to reverse feed cylinder installing base
󱀆
.
(2 pcs. each)
4) Install panel installing auxiliary plate
󱀅
to reverse
feed cylinder
󱀆
with setscrews
󱀇
. At this time,
atwashers
󱢳
are not used.
2) Install the operation box to panel installing aux-
iliary plate
󱀅
with screws
󱀃
and washers
󱀄
supplied as accessories.
󱀀
󱀁
󱀂
󰿿
󱀄
󱀃
󱀅
󱢳
󱀇
󱀇
󱢳
󱀅
󱀆
󱢴
󱢵
