Control and function elements
14
23 Connection cable: Voltage supply, refrigeration machine circulator
24 Electrical connection: Integrated connector to supply power to the circulator
25
Electrical connection: Integrated connector to supply power to the refrigeration
circulator
26 Drain cock and drain port (behind ventilation grille)
27 Caps (connectors for the cooling coil)
Accessories, included in the supply
1x Main cable for voltage supply for the
refrigeration machine (23) and circulator (11)
(use one only for refrigeration circulator)
1x Connection cable: Refrigeration machine (22) Circulator
(11)
With Refrigerated Circulators
1x CAN connection cable (18, for refrigeration machine
circulator)
