Jungheinrich EKS 410 User Manual

0708.GB
B 6
3.2 Dimensions (as per data plate)
1)
ZT mast performance data measured for 400 ZT.
2)
ZT mast performance data measured for 350 ZT.
3)
ZT mast performance data measured for 500 ZT.
Description EKS
410
EKS
513
EKS
515k
EKS
515
h
1
Mast height
(retracted)
3100
1)
2955
2)
2955
2)
3705
3)
mm
h
3
Lift 4000
1)
3500
2)
3500
2)
5000
3)
mm
h
4
Mast height
(extended)
6550
1)
6050
2)
6050
2)
7550
3)
mm
h
7
Seat height / standing height 395 470 470 470 mm
h
9
Aux. lift 840 840 840 840 mm
h
10
Overall lift 4840
1)
4340
2)
4340
2)
5840
3)
mm
h
15
Stockpicking height 5995
1)
5570
2)
5570
2)
7070
3)
mm
Ast Working aisle width for
pallets 1000 x 1200 traverse
1640 1640 1640 1640 mm
b
2
Overall width 1440 1450 1500 1500 mm
b
5
Distance between forks,
outer
(PAL width 1200)
793 535 535 535 mm
b
6
Width across guide rollers 1620 1540 1540 1540 mm
l
1
Overall length w.o. load
(PAL width 1200)
3577 3340 3440 3736 mm
l
2
Length including fork back
(PAL width 1200)
3273 3200 3300 3596 mm
l Fork length 1200 1200 1200 1200 mm
W
a
Turning radius 2035 2101 2201 2497 mm
m
2
Ground clearance centre
wheelbase
80 85 85 85 mm
Net weight incl. battery, w.o.
load
5218 6499 6926 8083 kg
0708.GB
B 6
3.2 Dimensions (as per data plate)
1)
ZT mast performance data measured for 400 ZT.
2)
ZT mast performance data measured for 350 ZT.
3)
ZT mast performance data measured for 500 ZT.
Description EKS
410
EKS
513
EKS
515k
EKS
515
h
1
Mast height
(retracted)
3100
1)
2955
2)
2955
2)
3705
3)
mm
h
3
Lift 4000
1)
3500
2)
3500
2)
5000
3)
mm
h
4
Mast height
(extended)
6550
1)
6050
2)
6050
2)
7550
3)
mm
h
7
Seat height / standing height 395 470 470 470 mm
h
9
Aux. lift 840 840 840 840 mm
h
10
Overall lift 4840
1)
4340
2)
4340
2)
5840
3)
mm
h
15
Stockpicking height 5995
1)
5570
2)
5570
2)
7070
3)
mm
Ast Working aisle width for
pallets 1000 x 1200 traverse
1640 1640 1640 1640 mm
b
2
Overall width 1440 1450 1500 1500 mm
b
5
Distance between forks,
outer
(PAL width 1200)
793 535 535 535 mm
b
6
Width across guide rollers 1620 1540 1540 1540 mm
l
1
Overall length w.o. load
(PAL width 1200)
3577 3340 3440 3736 mm
l
2
Length including fork back
(PAL width 1200)
3273 3200 3300 3596 mm
l Fork length 1200 1200 1200 1200 mm
W
a
Turning radius 2035 2101 2201 2497 mm
m
2
Ground clearance centre
wheelbase
80 85 85 85 mm
Net weight incl. battery, w.o.
load
5218 6499 6926 8083 kg
