2Battery types

The EKS can be fitted with a variety of battery types. All battery types comply with

DIN 43531-A. The following table shows which combinations can be included as

standard:

The battery weights can be taken from the battery data plate.

The weight and dimensions of the battery have a considerable effect on the

operational safety of the industrial truck. Battery equipment may only be replaced with

the agreement of the manufacturer.

3 Charge the battery

Park the truck securely (see Chapter E).

– Turn key switch to "0" (zero).

– Fully open the battery panels.

Only connect and disconnect the battery connector and the socket when the mains

and charger are switched off.

– Disconnect the battery.

– If necessary, remove the insulating mat from the battery.

When charging, the tops of the battery cells must be exposed to provide sufficient

ventilation. Do not place any metal objects on the battery. Before charging, check all

cables and plug connections for visible signs of damage.

– Connect the charger lead of the battery charger station with the battery connector.

– Switch on the charger.

– Charge the battery in accordance with the battery and charging station

manufacturers’ instructions.

It is essential to follow the safety regulations of the battery and charger station

manufacturers.

Battery type Battery type Truck type

48V 4EPzS460 Single part EKS 410

48V 4EPzS575 Single part EKS 410

48V 4EPzS690 Single part EKS 410

80V 3EPzS420 Single part / two part EKS 513 / EKS 515k

80V 4EPzS560 Single part / two part EKS 515k

80V 5EPzS700 Single part / two part EKS 515

80V 6EPzS840 Single part / two part EKS 515
