0708.GB
F 4
4 EKS Maintenance Checklist
b) applies only to the EKS 513-515
Maintenance intervals
Standard = t WABC
Chassis/
Structure:
1.1 Check all load bearing components for damage t
1.2 Check screw connections t
1.3 Test the operator’s platform and check for damage t
1.4 Check that identification points, data plates and
warnings are legible and replace if necessary
t
1.5 Check battery panel and sides are secure t
1.6 Test gas pressure damper and check for damage b) t
Drive: 2.1 Lubricate the bearing between the drive motor and
transmission
t
2.2 Check transmission for noise and leakage t
2.3 Change transmission oil t
Wheels: 3.1 Check wheels for wear and damage t
3.2 Check bearings and attachment t
Steering: 4.1 Test wheel position indicator t
4.2 Check the distance between the guide rollers and the
rail guidance over the entire length of the rails. The play
between the two guide rollers and the rails (measured
over the axle) should be 0-5 mm. The rollers should not
jam.
t
Brake
system:
5.1 Test operation and settings t
5.2 Check the brake lining wear t
5.3 Check the brake linkage; adjust and grease
as required b)
t
5.4 Check brake lines, connections and brake fluid level b) t
5.5 Check brake fluid b) t
5.6 Replace brake fluid b) t
0708.GB
F 4
4 EKS Maintenance Checklist
b) applies only to the EKS 513-515
Maintenance intervals
Standard = t WABC
Chassis/
Structure:
1.1 Check all load bearing components for damage t
1.2 Check screw connections t
1.3 Test the operator’s platform and check for damage t
1.4 Check that identification points, data plates and
warnings are legible and replace if necessary
t
1.5 Check battery panel and sides are secure t
1.6 Test gas pressure damper and check for damage b) t
Drive: 2.1 Lubricate the bearing between the drive motor and
transmission
t
2.2 Check transmission for noise and leakage t
2.3 Change transmission oil t
Wheels: 3.1 Check wheels for wear and damage t
3.2 Check bearings and attachment t
Steering: 4.1 Test wheel position indicator t
4.2 Check the distance between the guide rollers and the
rail guidance over the entire length of the rails. The play
between the two guide rollers and the rails (measured
over the axle) should be 0-5 mm. The rollers should not
jam.
t
Brake
system:
5.1 Test operation and settings t
5.2 Check the brake lining wear t
5.3 Check the brake linkage; adjust and grease
as required b)
t
5.4 Check brake lines, connections and brake fluid level b) t
5.5 Check brake fluid b) t
5.6 Replace brake fluid b) t
