Jungheinrich EKS 410 User Manual

B 7
0708.GB
3.3 EKS 410 mast version
3.4 EKS 513 – 515 mast version
Description EKS 410
h
1
Retracted height (ZT) 2550 - 4100 mm
h
3
Lift 2500 - 6000 mm
h
4
Extended height 5050 - 8550 mm
h
6
Height above overhead
guard
2550 mm
h
9
Aux. lift 840 mm
h
10
Overall lift height 3340 - 6840 mm
h
15
Stockpicking height 4495 - 7995 mm
Description EKS
513
EKS
515k
EKS
515
h
1
Retracted height (ZT) 2705 - 5055 2705 - 6155 2705 - 6405 mm
h
1
Retracted height (DZ) 2595 - 3895 2595 - 4695 2595 - 5795 mm
h
3
Lift (ZT) 3000 - 7500 3000 - 9500 3000 - 10000 mm
h
3
Lift (DZ) 4250 - 7500 4250 - 9500 4250 - 12500 mm
h
4
Extended height (ZT) 5550 - 10050 5550 - 12050 5550 - 12550 mm
h
4
Extended height (DZ) 6800 - 10050 6800 - 12050 6800 - 15050 mm
h
6
Height above overhead
guard
2550 2550 2550 mm
h
9
Aux. lift 840 840 840 mm
h
10
Overall lift height (ZT) 3840 - 8340 3840 - 10340 3840 - 10840 mm
h
10
Overall lift height (DZ) 5090 - 8340 5090 - 10340 5090 - 13340 mm
h
15
Picking height (ZT) 5070 - 9570 5070 - 11570 5070 - 12070 mm
h
15
Picking height (DZ) 6320 - 9570 6320 - 11570 5070 - 14570 mm
B 7
0708.GB
3.3 EKS 410 mast version
3.4 EKS 513 – 515 mast version
Description EKS 410
h
1
Retracted height (ZT) 2550 - 4100 mm
h
3
Lift 2500 - 6000 mm
h
4
Extended height 5050 - 8550 mm
h
6
Height above overhead
guard
2550 mm
h
9
Aux. lift 840 mm
h
10
Overall lift height 3340 - 6840 mm
h
15
Stockpicking height 4495 - 7995 mm
Description EKS
513
EKS
515k
EKS
515
h
1
Retracted height (ZT) 2705 - 5055 2705 - 6155 2705 - 6405 mm
h
1
Retracted height (DZ) 2595 - 3895 2595 - 4695 2595 - 5795 mm
h
3
Lift (ZT) 3000 - 7500 3000 - 9500 3000 - 10000 mm
h
3
Lift (DZ) 4250 - 7500 4250 - 9500 4250 - 12500 mm
h
4
Extended height (ZT) 5550 - 10050 5550 - 12050 5550 - 12550 mm
h
4
Extended height (DZ) 6800 - 10050 6800 - 12050 6800 - 15050 mm
h
6
Height above overhead
guard
2550 2550 2550 mm
h
9
Aux. lift 840 840 840 mm
h
10
Overall lift height (ZT) 3840 - 8340 3840 - 10340 3840 - 10840 mm
h
10
Overall lift height (DZ) 5090 - 8340 5090 - 10340 5090 - 13340 mm
h
15
Picking height (ZT) 5070 - 9570 5070 - 11570 5070 - 12070 mm
h
15
Picking height (DZ) 6320 - 9570 6320 - 11570 5070 - 14570 mm
