B 9
0708.GB
4 Identification points and data plates
F
Warning and information labels, such as capacity diagrams, attachment points and
identification plates, must be readable at all times or be replaced, if necessary.
EKS 410
Item Description
6 Strap points for crane lifting
7 Truck data plate
8 Capacity plate
9 Decal: “Abseil device”
10 Decal: “No passengers”
11 Test sticker (o)
12 Decal: Do not step onto or beneath the load, risk of trapping
13 Jack contact points
14 Serial number (engraved in chassis underneath the battery cover)
15 “Add hydraulic oil” notice
16 “Emergency drain” decal
17 “Emergency drain key” decal
18 Decal: “Caution: Low voltage electronics system"
19 “Read operating instructions" notice
