Serial number locaon The serial number label is located as shown in Figure 41 on page 83.
Figure 41: SRX5K-SCB3 Serial Number Label
SRX5K-SCB3 LEDs
Table 3 on page 83 describes the SCB3 LEDs and their states.
Table 3: SRX5K-SCB3 LEDs
Label Color State Descripon
FABRIC ACTIVE Green On steadily Fabric is in acve mode.
OK/FAIL Green On steadily SCB3 is online.
Red On steadily SCB3 has failed.
O SCB3 is oine.
LINK Green On steadily Port is enabled and link is established.
O Port is disabled or no link is established.
83
