CHAPTER 8
Handling and Storing SRX5400, SRX5600, and
SRX5800 Services Gateway Cards
IN THIS CHAPTER
SRX5400, SRX5600, and SRX5800 Services Gateway Card Terminology | 91
Handling an SRX5400, SRX5600, or SRX5800 Services Gateway Card | 92
Storing an SRX5600, SRX5600, or SRX5800 Services Gateway Card | 94
SRX5400, SRX5600, and SRX5800 Services Gateway Card Terminology
Regardless of orientation, this information uses the same terms for all four edges of the card (see
Figure 48 on page 92):
•
Faceplate—Edge of the card that has connectors to which you connect cables or sockets in which you
insert SFP or XFP transceivers.
•
Connector edge—Edge opposite the faceplate; this edge has the connectors that attach to the midplane.
•
Top edge—Edge at the top of the card when it is vertical.
•
Bottom edge—Edge at the bottom of the card when it is vertical.
NOTE: This terminology applies to SPCs, IOCs, MPCs, and SCBs in addition to Routing Engines
and port modules.
