1-2 (No.MB014)
SPECIFICATION
CA-HXZ10
SP-HXZ10
Design and specifications are subject to change without notice.
Amplifier section Output Power (IEC 268-3)
Subwoofer 125 W per channel, min. RMS, driven into 6 Ω at 63 Hz with no more than
10% total harmonic distortion.
Main Speaker 35 W per channel, min. RMS, driven into 6 Ω at 1 kHz with no more than 10%
total harmonic distortion.
Audio input sensitivity/impedance (Measured at 1 kHz, with tape recording signal 300 mV)
AUX 300 mV/47 kΩ
Speakers/impedance Subwoofer 6 Ω - 16 Ω
Main Speaker 6 Ω - 16 Ω
Tuner FM tuning range 87.50 MHz - 108.00 MHz
AM tuning range 522 kHz - 1 629 kHz
CD player Disc capacity 5 discs
Dynamic range 87 dB
Signal-to-noise ratio 90 dB
Wow and flutter Immeasurable
MP3 recording format MPEG 1/2 Audio Layer 3
Max. Bit rate 320 kbps
Cassette deck Frequency response Normal (type I) 50 Hz - 14 000 Hz
Wow and flutter 0.15% (WRMS)
General Power requirement AC 230 V , 50 Hz
Power consumption 165 W (in operation)
27 W (on standby with Ecology Mode off)
1.2 W (on standby with Ecology Mode on)
Dimensions (approx.) 205 mm × 370 mm × 380.5 mm (W/H/D)
Mass (approx.) 10.5 kg
Type 3-way 4-speaker Bass-Reflex Type Twin Hyper Power-Drive Subwoofer and Front Twin
Woofer
Speakers Subwoofer 16.0 cm (6-5/16 in.) cone × 1
Main woofer 10.0 cm (3-15/16 in.) cone × 2
Tweeter 5.0 cm (2 in.) cone × 1
Power Handling Capacity Subwoofer 165 W
Main Speaker 75 W
Impedance Subwoofer 6 Ω
Main Speaker 6 Ω
Frequency Range Subwoofer 30 Hz ~ 325 Hz
Main Speaker 70 Hz ~ 32 000 Hz
Sound Pressure Level 78 dB/W·m
Subwoofer 86 dB/W·m
Main Speaker 220 mm × 432 mm × 357 mm
Dimensions (W × H × D) 8-11/16 in. × 17-1/16 in. × 14-1/16 in.)
Mass 8.2 kg (18.1 lbs) each
