JVC HX-Z10 Service Manual

3-14
Front board
Block No. [0][3][0][0]
R492 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R493 QRE141J-224Y C RESISTOR 220k Ω 1/4W J
R494 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
R495 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R496 QRE141J-154Y C RESISTOR 150k Ω 1/4W J
R497 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R498 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R499 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R500 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R501 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R502 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R503 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R504 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R505 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R506 QRE141J-822Y C RESISTOR 8.2k Ω 1/4W J
R507 QRE141J-113Y C RESISTOR 11k Ω 1/4W J
R508 QRE141J-152Y C RESISTOR 1.5k Ω 1/4W J
R509 QRE141J-124Y C RESISTOR 120k Ω 1/4W J
R510 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R511 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R512 QRE141J-223Y C RESISTOR 22k
Ω 1/4W J
R513 QRE141J-223Y C RESISTOR 22k
Ω 1/4W J
R514 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R515 QRE141J-512Y C RESISTOR 5.1k Ω 1/4W J
R516 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
R517 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R518 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R519 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R520 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R521 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R522 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R523 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R524 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R530 QRE141J-225Y C RESISTOR 2.2M Ω 1/4W J
R531 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R532 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
R533 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R534 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R535 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
 R601 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
 R602 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
R603 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R604 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R605 FQRJ143J-122X UNF C RESISTOR
 R606 FQRJ143J-122X UNF C RESISTOR
R607 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R608 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R613 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R614 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R615 FQRJ143J-100X UNF C RESISTOR
 R616 FQRJ143J-100X UNF C RESISTOR
R617 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R618 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R619 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R620 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R621 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R623 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
 R637 QRK126J-151X UNF C RESISTOR 150 Ω 1/2W J
 R638 QRK126J-151X UNF C RESISTOR 150 Ω 1/2W J
 R639 QRL01DJ-821X OMF RESISTOR 820 Ω 1W J
 R640 QRL01DJ-821X OMF RESISTOR 820 Ω 1W J
 R641 QRK126J-151X UNF C RESISTOR 150 Ω 1/2W J
 R642 QRL01DJ-821X OMF RESISTOR 820 Ω 1W J
 R643 QRL01DJ-821X OMF RESISTOR 820 Ω 1W J
R650 QRZ9006-4R7X F.RESISTOR 4.7 Ω 1/4W J
R651 QRZ9006-4R7X F.RESISTOR 4.7
Ω 1/4W J
 R652 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
 R654 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
R666 QRE141J-333Y C RESISTOR 33k
Ω 1/4W J
R667 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R668 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
 R674 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R675 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R676 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R680 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R682 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R683 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R725 QRE141J-823Y C RESISTOR 82k
Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
R726 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R731 QRZ9006-4R7X F.RESISTOR 4.7 Ω 1/4W J
R732 QRZ9006-4R7X F.RESISTOR 4.7 Ω 1/4W J
R733 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R734 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R735 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R736 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
 R737 QRK126J-151X UNF C RESISTOR 150 Ω 1/2W J
 R738 QRK126J-151X UNF C RESISTOR 150 Ω 1/2W J
 R743 QRK126J-151X UNF C RESISTOR 150 Ω 1/2W J
L411 QQR1183-001Z FERRITE BEADS
L522 QQL231K-101Y COIL 100uH K
L601 QQLZ035-R39 COIL 0.39uH
L602 QQLZ035-R39 COIL 0.39uH
L703 QQL231K-470Y COIL 47uH K
CN11 QGF1205F1-11 CONNECTOR FFC/FPC (1-11)
CN44 QGF1201F3-10 CONNECTOR FFC/FPC (1-10)
CN205 QGB2510J1-15 CONNECTOR B-B (1-15)
CN206 QGA2501F1-02 CONNECTOR W-B (1-2)
CN207 QGB2510K2-06 CONNECTOR B-B (1-6)
CN217 QGB2510J1-06 CONNECTOR B-B (1-6)
CN311 QGB2510J1-13 CONNECTOR B-B (1-13)
CN661 QGF1036F1-17 CONNECTOR FFC/FPC (1-17)
CN701 QGD2503F1-04 CONNECTOR (1-4)
CN870 QGF1205F1-23 CONNECTOR FFC/FPC (1-23)
FW202 QUM157-07DGZ4 FW CABLE
FW204 QJK015-050604 WIRE SOCKET
J81 QNB0171-001 SPK.TERMINAL
J411 QNN0420-001 PIN JACK
RY1 QSK0109-001 RELAY
RY2 QSK0109-001 RELAY
SP425 GV40205-001A IC HOLDER
TW409 QUB230-06HPHP WIRE ASSY
X522 QAX0263-001Z CRYSTAL 4.332MHz
 Symbol No. Part No. Part Name Description Local
IC810 UPD784215AGF535 IC
IC951 GP1UM271XK IR DETECT UNIT
IR detecting unit for
remote control
Q821 KRC102M-T DIGI TRANSISTOR
Q822 KRC102M-T DIGI TRANSISTOR
Q823 KRC102M-T DIGI TRANSISTOR
Q824 KRC102M-T DIGI TRANSISTOR
Q825 KRC102M-T DIGI TRANSISTOR
Q826 KRC102M-T DIGI TRANSISTOR
Q827 KRC102M-T DIGI TRANSISTOR
Q828 KRC102M-T DIGI TRANSISTOR
Q829 KRC102M-T DIGI TRANSISTOR
Q830 KRC102M-T DIGI TRANSISTOR
Q833 KRA111M-T DIGI TRANSISTOR
Q834 KRC102M-T DIGI TRANSISTOR
Q835 KRC102M-T DIGI TRANSISTOR
Q836 KRC102M-T DIGI TRANSISTOR
Q837 KRC102M-T DIGI TRANSISTOR
Q838 KRC102M-T DIGI TRANSISTOR
Q875 KRC102M-T DIGI TRANSISTOR
Q916 KTA1267/YG/-T TRANSISTOR
Q917 KRC102M-T DIGI TRANSISTOR
Q930 KRA102M-T DIGI TRANSISTOR
Q932 KRA102M-T DIGI TRANSISTOR
Q934 KRA102M-T DIGI TRANSISTOR
Q936 KRA102M-T DIGI TRANSISTOR
Q980 KRC102M-T DIGI TRANSISTOR
D801 1SS119-041-T2 DIODE
D802 1SS119-041-T2 DIODE
D803 1SS119-041-T2 DIODE
 Symbol No. Part No. Part Name Description Local
