3-7
CD changer mechanism
Block No. [M][A][M][M]
Symbol No.
Part No. Part Name Description Local
1 LV10743-001A CHASSIS ASSY
2 LV43278-001A SENSOR SPRING
3 LV33961-001A SENSOR SLIDER
4 LV33962-001A SENSOR BRACKET
5 QYSDST2605Z SCREW 2.6mm x 5mm(x2)
6 QVY0027-B14 S V RESISTOR
7 QYSDST2004Z SCREW 2mm x 4mm
8 QAR0164-001 MOTOR (x2)
9 LV42340-001A MOTOR PULLEY (x2)
10 LV41431-001A BELT (x2)
11 QYSPSPU1725N SCREW
1.7mm x
2.5mm(x4)
12 LV10744-001A RACK HOLDER
13 LV21406-001A LOADING RACK
14 LV43279-001A LIFT ARM ASSY
15 LV33963-001A HOOK
16 LV33964-001A HOOK STOPPER
17 QYSDST2605Z SCREW 2.6mm x 5mm(x3)
18 LV33965-003A LIFTER ASSY
19 LV21408-001A RAIL(R)
20 LV21409-001A RAIL(L)
21 LV43285-001A ROD (L)
22 LV21520-001A SIDE(R) ASSY
23 LV33974-001A SELECT LEVER
24 LV33975-001A GEAR COVER
25 LV33976-001A ELEVATOR CAM
26 LV43287-001A ELEVATOR SPRING
27 LV33977-002A CLICK SPRING
28 QYSDST2605Z SCREW 2.6mm x 5mm(x3)
29 LV10749-001A SIDE(L)
30 LV33980-001A OPEN DET.LEVER
31 QYSDST2605Z SCREW 2.6mm x 5mm(x2)
32 LV10746-001A TRAY ASSY (x5)
33 LV10750-001A TOP COVER
34 LV43289-001A ROD (x2)
35 QYSDSF2608Z SCREW 2.6mm x 8mm(x2)
36 QYSDST2605Z SCREW 2.6mm x 5mm(x2)
37 QYSDSF2608Z SCREW 2.6mm x 8mm
38 QYSDST2605Z SCREW 2.6mm x 5mm
39 QYSDST2004Z SCREW 2mm x 4mm
40 WJM0330-001A E-SI C WIRE C-F
41 WJM0331-001A E-SI C WIRE C-F
42 QUQ110-1521BF FFC WIRE
43 VYSA1R4-056 SPACER
44 ------------ CD TRAMECHA ASS
45 VKS3697-001 CLAMPER
46 VYH7313-003 MAGNET
47 LV33981-001A CD YOKE
48 QYSDSF2606Z SCREW 2.6mm x 6mm
49 LV41659-002A INSULATOR (x4)
50 LV43245-001A SPECIAL SCREW (x4)
51 LV21410-001A CD TM BASE
52 QYSDST2605Z SCREW 2.6mm x 5mm(x3)
53 LV21411-001A CD MODULE BKT
54 QYSDST2605Z SCREW 2.6mm x 5mm(x2)
55 QYSDSF2608Z SCREW 2.6mm x 8mm(x4)
56 QUQ610-1611AJ FFC WIRE
57 QJJ010-061802 SIN CR C-C WIRE
To Next Page
