JVC HX-Z10 Service Manual

3-12
Input board
Block No. [0][2][0][0]
RY3 QSK0124-001 RELAY
TW215 QUB350-09HPHP FLAT WIRE
TW216 QUB230-06HPHP WIRE ASSY
 Symbol No. Part No. Part Name Description Local
 IC240 KIA7812API IC Regulator
IC415 BA033T REGULATOR IC Regurator
IC425 M61519FP VOLUME IC
Audio signal
proccessor with
surround
IC466 HA17558A IC
Dual Operational
Amp
IC467 HA17558A IC
Dual Operational
Amp
IC491 HA17558A IC
Dual Operational
Amp
IC492 HA17558A IC
Dual Operational
Amp
IC522 LC72723 IC(RDS)
IC602 STK432-050 IC
Q201 KTC1027/OY/-T TRANSISTOR
Q202 2SC2785/FE/-T TRANSISTOR
Q260 KTC3203/OY/-T TRANSISTOR
Q415 KRC104M-T TRANSISTOR
Q416 KRC102M-T DIGI TRANSISTOR
Q486 2SC2785/FE/-T TRANSISTOR
Q487 2SC2785/FE/-T TRANSISTOR
Q491 2SC2785/FE/-T TRANSISTOR
Q492 2SC2785/FE/-T TRANSISTOR
Q493 2SC2785/FE/-T TRANSISTOR
Q513 2SC3576-JVC-T TRANSISTOR
Q514 2SC3576-JVC-T TRANSISTOR
Q515 2SC3576-JVC-T TRANSISTOR
Q516 2SC3576-JVC-T TRANSISTOR
Q517 2SC3576-JVC-T TRANSISTOR
Q518 KRA102M-T DIGI TRANSISTOR
Q530 2SC2785/FE/-T TRANSISTOR
Q531 KRC111M-T TRANSISTOR
Q601 KTC3200/GL/-T TRANSISTOR
Q602 KTC3200/GL/-T TRANSISTOR
Q612 2SA1175/FE/-T TRANSISTOR
Q613 KRC102M-T DIGI TRANSISTOR
Q682 KTC3203/OY/-T TRANSISTOR
Q690 2SC2785/FE/-T TRANSISTOR
Q733 2SC3576-JVC-T TRANSISTOR
Q734 2SC3576-JVC-T TRANSISTOR
Q735 2SC3576-JVC-T TRANSISTOR
Q736 2SC3576-JVC-T TRANSISTOR
Q737 KRA111M-T DIGI TRANSISTOR
 D201 1N5402M-20 DIODE
 D202 1N5402M-20 DIODE
 D203 1N5402M-20 DIODE
 D204 1N5402M-20 DIODE
 D211 1N5402M-20 DIODE
 D212 1N5402M-20 DIODE
 D213 1N5402M-20 DIODE
 D214 1N5402M-20 DIODE
D219 MTZJ20B-T2 Z DIODE
D220 MTZJ6.8B-T2 Z DIODE
D221 1SS119-041-T2 DIODE
D222 MTZJ18B-T2 Z DIODE
D240 MTZJ13B-T2 Z DIODE
D260 1SS119-041-T2 DIODE
D261 1SS119-041-T2 DIODE
D262 1SS119-041-T2 DIODE
D263 1SS119-041-T2 DIODE
D264 MTZJ5.1B-T2 Z DIODE
D265 1SS119-041-T2 DIODE
D266 1SS119-041-T2 DIODE
 Symbol No. Part No. Part Name Description Local
D411 1SS119-041-T2 DIODE
D412 1SS119-041-T2 DIODE
D415 MTZJ3.9B-T2 Z DIODE
D425 1SS119-041-T2 DIODE
D466 1SS119-041-T2 DIODE
D467 1SS119-041-T2 DIODE
D486 1SS119-041-T2 DIODE
D491 1SS119-041-T2 DIODE
D492 1SS119-041-T2 DIODE
D513 MTZJ3.9B-T2 Z DIODE
D514 MTZJ3.9B-T2 Z DIODE
D522 1SS119-041-T2 DIODE
D530 1SS119-041-T2 DIODE
D619 1SS119-041-T2 DIODE
D620 1SS119-041-T2 DIODE
D622 MTZJ9.1B-T2 Z DIODE
D650 1SS119-041-T2 DIODE
D725 1SS119-041-T2 DIODE
C201 QFKC2EK-103Z MM CAPACITOR 0.01uF 250V K
C202 QFKC2EK-103Z MM CAPACITOR 0.01uF 250V K
C203 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K
C204 QEZ0621-478 E CAPACITOR 4700uF
C205 QEZ0621-478 E CAPACITOR 4700uF
C211 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C212 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C213 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K
C214 QETM1VM-228 E CAPACITOR 2200uF 35V M
C215 QETM1VM-228 E CAPACITOR 2200uF 35V M
C217 QETN1JM-107Z E CAPACITOR 100uF 63V M
C218 QETN1HM-226Z E CAPACITOR 22uF 50V M
C219 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C220 QETN1HM-226Z E CAPACITOR 22uF 50V M
C222 QETN1EM-106Z E CAPACITOR 10uF 25V M
C236 QETM1EM-688 E CAPACITOR 6800uF 25V M
C240 QETN1HM-106Z E CAPACITOR 10uF 50V M
C241 QETN1HM-106Z E CAPACITOR 10uF 50V M
C260 QETN1EM-476Z E CAPACITOR 47uF 25V M
C401 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C402 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C403 FQCF31HP-223Z M CAPACITOR
C404 FQCF31HP-103Z D.CAPACITOR
C408 FQCF31HP-103Z D.CAPACITOR
C409 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C410 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C411 QCBB1HK-222Y C CAPACITOR 2200pF 50V K
C412 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C413 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C415 QETN1AM-227Z E CAPACITOR 220uF 10V M
C417 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C418 QETN1HM-106Z E CAPACITOR 10uF 50V M
C419 QETN1HM-106Z E CAPACITOR 10uF 50V M
C420 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C422 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C423 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C425 QETN1HM-106Z E CAPACITOR 10uF 50V M
C426 QETN1HM-106Z E CAPACITOR 10uF 50V M
C427 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C428 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C429 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C430 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C431 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C432 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C433 QETN1EM-106Z E CAPACITOR 10uF 25V M
C434 QETN1EM-106Z E CAPACITOR 10uF 25V M
C436 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C437 QETN1CM-107Z E CAPACITOR 100uF 16V M
C438 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C440 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C441 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C442 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C443 QETN1HM-105Z E CAPACITOR 1uF 50V M
C444 QETN1HM-106Z E CAPACITOR 10uF 50V M
C445 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C446 QFLC1HJ-183Z M CAPACITOR 0.018uF 50V J
C447 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C448 QFLC1HJ-183Z M CAPACITOR 0.018uF 50V J
C449 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
 Symbol No. Part No. Part Name Description Local
