JVC HX-Z10 Service Manual

3-16
CD servo board
Block No. [0][4][0][0]
R919 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R920 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R921 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R922 QRE141J-121Y C RESISTOR 120 Ω 1/4W J
R923 QRE141J-151Y C RESISTOR 150 Ω 1/4W J
R924 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R925 QRE141J-271Y C RESISTOR 270
Ω 1/4W J
R926 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R927 QRE141J-561Y C RESISTOR 560 Ω 1/4W J
R928 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R930 QRE141J-181Y C RESISTOR 180 Ω 1/4W J
R932 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R933 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R934 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R935 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R936 QRE141J-181Y C RESISTOR 180 Ω 1/4W J
R938 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R940 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R941 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R942 QRE141J-121Y C RESISTOR 120 Ω 1/4W J
R943 QRE141J-151Y C RESISTOR 150
Ω 1/4W J
R944 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R945 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R946 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R947 QRE141J-561Y C RESISTOR 560 Ω 1/4W J
R948 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R949 QRE141J-182Y C RESISTOR 1.8k Ω 1/4W J
R950 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R959 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R960 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R961 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R968 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R970 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R971 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R972 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R973 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R974 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R980 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R981 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R982 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R983 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R998 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R999 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
L803 QQL29BJ-100Z COIL 10uH J
L805 QQR1183-001Z FERRITE BEADS
L806 QQR1183-001Z FERRITE BEADS
L1001 QQL231K-2R2Y COIL 2.2uH K
L1002 QQL231K-2R2Y COIL 2.2uH K
L1003 QQR1277-001Z COIL
BZ801 QAN0055-001 BUZZER
CN43 QGF1210G1-09 CONNECTOR FFC/FPC (1-9)
CN840 QGF1210G1-15 CONNECTOR FFC/FPC (1-15)
CN850 QGF1205F1-15 CONNECTOR FFC/FPC (1-15)
CN860 QGF1205C1-23 CONNECTOR FFC/FPC (1-23)
CN880 QGD2503F1-06 CONNECTOR (1-6)
CN900 QGD2503F1-05 CONNECTOR (1-5)
FL801 QLF0111-001 FL TUBE
FW221 QUM156-15DGZ4 FLAT WIRE
FW711 QUM154-33DGZ4 FLAT WIRE
FW800 QUM024-20Z4Z4 FLAT WIRE
FW890 QUM026-10DGZ4 FLAT WIRE
FW900 QUM023-10Z4Z4 WIRE
FW910 QUM025-10DGZ4 FLAT WIRE
FW920 QUM023-10Z4Z4 WIRE
FW950 QUM023-13Z4Z4 FLAT WIRE
J1001 QNS0204-001 PHONE JACK
JS958 QSW0862-001 ROTARY VR
JS960 QSW0983-001 ROTARY SW
JS962 QSW0983-001 ROTARY SW
S900 QSW0825-001Z TACT SW
S901 QSW0825-001Z TACT SW
S902 QSW0825-001Z TACT SW
S903 QSW0825-001Z TACT SW
S904 QSW0825-001Z TACT SW
S905 QSW0825-001Z TACT SW
S906 QSW0825-001Z TACT SW
 Symbol No. Part No. Part Name Description Local
S907 QSW0825-001Z TACT SW
S908 QSW0825-001Z TACT SW
S909 QSW0825-001Z TACT SW
S910 QSW0825-001Z TACT SW
S911 QSW0825-001Z TACT SW
S920 QSW0825-001Z TACT SW
S921 QSW0825-001Z TACT SW
S922 QSW0825-001Z TACT SW
S923 QSW0674-001Z TACT SW
S924 QSW0674-001Z TACT SW
S925 QSW0674-001Z TACT SW
S926 QSW0674-001Z TACT SW
S940 QSW0674-001Z TACT SW
S941 QSW0825-001Z TACT SW
S942 QSW0825-001Z TACT SW
S943 QSW0825-001Z TACT SW
S944 QSW0825-001Z TACT SW
S945 QSW0825-001Z TACT SW
S946 QSW0825-001Z TACT SW
S947 QSW0825-001Z TACT SW
S948 QSW0825-001Z TACT SW
S949 QSW0825-001Z TACT SW
S950 QSW0674-001Z TACT SW
SP810 VYH7653-001 IC HOLDER
SP889 VYSA1R3-049 SPECER
TW801 QUB220-09HPDT SINGLE WIRE
TW889 QUB230-07A5A5 WIRE
X801 QAX0724-001Z CRYSTAL 12.000000MHz
 Symbol No. Part No. Part Name Description Local
IC201 BR24C08FV-X IC
IC251 MN101C61GMB1 IC
IC601 AN22002A-W I.C
IC651 MN6627911AC1 IC
IC671 A42L2604V-45L IC
IC681 TC7SH32FU-X IC
IC682 TC74VHC08FT-X IC
IC691 XC6206P182M-X IC
IC801 AN4801SB-W IC
Q291 2SB1424/QR/-W TRANSISTOR
Q631 2SA1037AK/RS/-X TRANSISTOR
C201 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C251 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C252 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C253 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C255 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C258 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C259 NDC31HJ-101X C CAPACITOR 100pF 50V J
C291 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C603 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C604 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C605 NDC31HJ-331X C CAPACITOR 330pF 50V J
C606 NDC31HJ-151X C CAPACITOR 150pF 50V J
C610 NCB31CK-563X C CAPACITOR 0.056uF 16V K
C611 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C612 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C614 NCB31CK-393X C CAPACITOR 0.039uF 16V K
C615 NCB31HK-272X C CAPACITOR 2700pF 50V K
C616 NCB31HK-182X C CAPACITOR 1800pF 50V K
C621 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C622 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C623 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C624 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C631 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C632 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C633 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C641 NDC31HJ-4R0X C CAPACITOR 4pF 50V J
C651 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
 Symbol No. Part No. Part Name Description Local
