MX-J170V
1-39
RAB41 microcontroller interface R/
W and load control line input (4-wire bus mode)
SILD42 microcontroller interface
R/W and load control line input (4-wire bus mode)
STATUS43 servo interrupt request line/decoder status register output (open-drain)
TEST344 test control input 3 (this pin should be tied LOW)
RCK45 subcode clock input
SUB46 P-to-W subcode bits output (3-state)
SFSY47 subcode frame sync output (3-state)
SBSY48 subcode block sync output (3-state)
CL11/449 11.2896 or 4.2336 MHz (for microcontroller) clock output
V
SSD2
50
(1)
digital ground 2
DOBM51 bi-phase mark output (externally buffered; 3-state)
V
DDD1(P)
52
(1)
digital supply voltage 1 for periphery
CFLG53 correction ßag output (open-drain)
RA54 radial actuator output
FO55 focus actuator output
SL56 sledge control output
V
DDD2(C)
57
(1)
digital supply voltage 2 for core
V
SSD3
58
(1)
digital ground 3
MOTO159 motor output 1; versatile (3-state)
MOTO260 motor output 2; versatile (3-state)
V461 versatile output 4
V562 versatile output 5
V163 versatile input 1
LDON64 laser drive on output (open-drain)
Function
2. Pin function(2/2)
Pin No.
Symbol
