JVC MX-J170V - Electrical Parts List (Main Board)

MX-J170V
3-8
Item
Parts number Parts name Area
Electrical parts list(Main board)
Remarks
Block No. 01
A
AC 1 2401-001954 E CAPACITOR
AC 2 2401-001954 E CAPACITOR
AC 3 2401-001912 E CAPACITOR
AC 4 2401-001975 C CAPACITOR
AC 5 2401-000970 E CAPACITOR
AC 6 2202-000821 C CAPACITOR
AC 8 2202-000817 C CAPACITOR
AC 10 2202-000854 C CAPACITOR
AC 11 2202-000854 C CAPACITOR
AC 13 2202-000817 C CAPACITOR
AC 14 2401-001912 E CAPACITOR
AC 15 2401-000970 E CAPACITOR
AC 16 2401-001954 E CAPACITOR
AC 17 2401-001954 E CAPACITOR
AC 18 2401-001975 C CAPACITOR
AC 19 2202-000821 C CAPACITOR
AC 20 2301-000375 C CAPACITOR
AC 21 2301-000375 C CAPACITOR
AC 22 2401-001092 E CAPACITOR
AC 23 2401-002180 E CAPACITOR
AC 24 2401-002180 E CAPACITOR
AC 25 2401-001538 E CAPACITOR
AC101 2401-001975 C CAPACITOR
AC102 2401-000419 E CAPACITOR
AD 1 0401-000101 DIODE 1N4148
AD 2 0401-000101 DIODE 1N4148
AD 3 0401-000101 DIODE 1N4148
AD 10 0401-000101 DIODE 1N4148
AIC 1 1201-001654 IC
A
7295
AIC 2 1201-001654 IC
A
7295
AJACK 3716-000209 TERMINAL BLOCK
AJW 1 AH39-00157D LEAD-CONNECTOR
A
Q
1 0504-000118 TRANSISTOR KSR1003
A
Q
6 0504-001003 TRANSISTOR KSR2003
A
Q
7 0501-000294 TRANSISTOR KSA708-Y
AR 1 2001-000890 C RESISTOR
AR 2 2001-000290 C RESISTOR
AR 3 2001-000522 C RESISTOR
AR 6 2001-000924 C RESISTOR
AR 7 2001-000786 C RESISTOR
AR 10 2001-000522 C RESISTOR
AR 12 2001-000290 C RESISTOR
AR 18 2001-000924 C RESISTOR
AR 20 2001-000786 C RESISTOR
AR 24 2001-000522 C RESISTOR
AR 30 2003-000689 OM RESISTOR
AR 31 2003-000689 OM RESISTOR
AR 32 2001-000290 C RESISTOR
AR 33 2001-000786 C RESISTOR
AR 34 2001-000591 C RESISTOR
AR 36 2001-000429 C RESISTOR
AR 39 2001-000522 C RESISTOR
AR100 2001-000429 C RESISTOR
AR203 2001-000660 C RESISTOR
AR204 2001-000008 C RESISTOR
AR205 2001-000008 C RESISTOR
AR206 2001-000977 C RESISTOR
AR208 2001-000429 C RESISTOR
CCW 1 3710-001567 CONNECTOR
CCW 2 3710-001571 CONNECTOR
CON 1 AH39-50001L LEAD-FASTEN
CONA- 3811-000131 WIRE-PVC CU
D 200 2301-000407 C CAPACITOR
DC 1 2301-000412 C CAPACITOR
DC 2 2301-000379 C CAPACITOR
DC 3 2301-000404 C CAPACITOR
DC 4 2301-000422 M CAPACITOR
DC 5 2201-000368 C CAPACITOR
DC 6 2201-000368 C CAPACITOR
DC 7 2401-001912 E CAPACITOR
DC 9 2301-000390 C CAPACITOR
DC 10 2301-000379 C CAPACITOR
DC 11 2301-000370 C CAPACITOR
DC 12 2301-000370 C CAPACITOR
DC 13 2401-001022 E CAPACITOR
DC 14 2401-001975 C CAPACITOR
DC 15 2401-000240 E CAPACITOR
DC 16 2301-000474 C CAPACITOR
DC 17 2301-000393 C CAPACITOR
DC 18 2301-000375 C CAPACITOR
DC 19 2401-002180 E CAPACITOR
DC 20 2401-001954 E CAPACITOR
DC 21 2401-001022 E CAPACITOR
DC 22 2202-000781 C CAPACITOR
DC 23 2401-001975 C CAPACITOR
DC 24 2401-000795 E CAPACITOR
DC 25 2401-001022 E CAPACITOR
DC 26 2201-000300 C CAPACITOR
DC 27 2301-000400 C CAPACITOR
DC 31 2401-001080 E CAPACITOR
DC 32 2401-001022 E CAPACITOR
DC 33 2401-001912 E CAPACITOR
DC 34 2401-001080 E CAPACITOR
DC 36 2201-000300 C CAPACITOR
DC 37 2301-000400 C CAPACITOR
DC 38 2401-001022 E CAPACITOR
DC 39 2401-001975 C CAPACITOR
DC 40 2202-000781 C CAPACITOR
DC 41 2401-001022 E CAPACITOR
DC 42 2301-000375 C CAPACITOR
DC 43 2202-000781 C CAPACITOR
DC 44 2401-002180 E CAPACITOR
DC 45 2202-000781 C CAPACITOR
DC 46 2202-000781 C CAPACITOR
DC 47 2301-000400 C CAPACITOR
DC 48 2202-000796 C CAPACITOR
DC 49 2401-000240 E CAPACITOR
DC 50 2401-001975 C CAPACITOR
DC 51 2301-000393 C CAPACITOR
DC 52 2401-001022 E CAPACITOR
DC 54 2301-000390 C CAPACITOR
DC 55 2301-000370 C CAPACITOR
DC 56 2301-000370 C CAPACITOR
DC 57 2301-000379 C CAPACITOR
DC 58 2301-000474 C CAPACITOR
DC 59 2401-000438 E CAPACITOR
DC 60 2401-000438 E CAPACITOR
DC 61 2401-001022 E CAPACITOR
DC 62 2401-001912 E CAPACITOR
DC 63 2202-000821 C CAPACITOR
DC 64 2202-000821 C CAPACITOR
DC 70 2401-001895 E CAPACITOR
DC 71 2202-000781 C CAPACITOR
DC 72 2202-000781 C CAPACITOR
DC 73 2301-000400 C CAPACITOR
DC 74 2202-000243 C CAPACITOR
Item
Parts number Parts name Area
Remarks
A
Electrical parts list
