MX-J170V
3-9
Item
Parts number Parts name Area
Electrical parts list(Main board)
Remarks
Block No. 01
A
DC 75 2202-000243 C CAPACITOR
DC301 2202-000781 C CAPACITOR
DC302 2202-000781 C CAPACITOR
DC303 2202-000781 C CAPACITOR
DD 1 0401-000101 DIODE 1N4148
DD 2 0401-000101 DIODE 1N4148
DD 3 0401-000101 DIODE 1N4148
DD 4 0401-000101 DIODE 1N4148
DIC 1 1201-000358 IC 22291
DIC 2 1201-000191 IC 4558
DL 1 AH26-10002Y COIL
DL 2 AH26-10002Y COIL
DL 5 AH27-00018A COIL LTRT1500-X00021
DL 6 2701-000298 INDUCTOR-AXIAL
D
Q
1 0501-000369 TRANSISTOR KSC2331-Y
D
Q
2 0501-000610 TRANSISTOR KSA928A-Y
D
Q
3 0501-000398 TRANSISTOR KSC945
D
Q
4 0504-000118 TRANSISTOR KSR1003
D
Q
5 0501-000010 TRANSISTOR KSC1008
D
Q
6 0501-000010 TRANSISTOR KSC1008
D
Q
7 0501-000010 TRANSISTOR KSC1008
D
Q
8 0501-000010 TRANSISTOR KSC1008
D
Q
9 0504-001003 TRANSISTOR KSR2003
D
Q
10 0504-000118 TRANSISTOR KSR1003
D
Q
11 0501-000398 TRANSISTOR KSC945
D
Q
12 0501-000398 TRANSISTOR KSC945
D
Q
13 0501-000398 TRANSISTOR KSC945
D
Q
14 0501-000398 TRANSISTOR KSC945
D
Q
15 0504-001003 TRANSISTOR KSR2003
D
Q
16 0501-000398 TRANSISTOR KSC945
D
Q
17 0501-000398 TRANSISTOR KSC945
D
Q
18 0504-001003 TRANSISTOR KSR2003
D
Q
20 0504-000118 TRANSISTOR KSR1003
DR 1 2001-000440 C RESISTOR
DR 2 2001-000440 C RESISTOR
DR 3 2001-000734 C RESISTOR
DR 5 2001-000290 C RESISTOR
DR 6 2001-001096 C RESISTOR
DR 7 2001-000786 C RESISTOR
DR 8 2001-000591 C RESISTOR
DR 9 2001-000290 C RESISTOR
DR 10 2001-000429 C RESISTOR
DR 11 2001-000734 C RESISTOR
DR 12 2001-000924 C RESISTOR
DR 13 2001-000003 C RESISTOR
DR 15 2001-000290 C RESISTOR
DR 16 2001-000290 C RESISTOR
DR 18 2001-000734 C RESISTOR
DR 19 2001-000290 C RESISTOR
DR 20 2001-000977 C RESISTOR
DR 21 2001-000397 C RESISTOR
DR 22 2001-000890 C RESISTOR
DR 23 2001-000003 C RESISTOR
DR 24 2001-000786 C RESISTOR
DR 25 2001-000890 C RESISTOR
DR 26 2001-000708 C RESISTOR
DR 27 2001-000331 C RESISTOR
DR 28 2001-000325 C RESISTOR
DR 40 2001-000522 C RESISTOR
DR 41 2001-000734 C RESISTOR
DR 42 2001-000613 C RESISTOR
DR 43 2001-000258 C RESISTOR
DR 47 2001-000522 C RESISTOR
DR 48 2001-000591 C RESISTOR
DR 49 2001-000734 C RESISTOR
DR 50 2001-000613 C RESISTOR
DR 58 2001-000325 C RESISTOR
DR 59 2001-000331 C RESISTOR
DR 61 2001-000734 C RESISTOR
DR 62 2001-000786 C RESISTOR
DR 63 2001-000591 C RESISTOR
DR 64 2001-000290 C RESISTOR
DR 65 2001-000429 C RESISTOR
DR 66 2001-000003 C RESISTOR
DR 67 2001-000924 C RESISTOR
DR 68 2001-000290 C RESISTOR
DR 69 2001-000331 C RESISTOR
DR 70 2001-000003 C RESISTOR
DR 71 2001-000397 C RESISTOR
DR 72 2001-000977 C RESISTOR
DR 73 2001-000449 C RESISTOR
DR 74 2001-000786 C RESISTOR
DR 75 2001-000449 C RESISTOR
DR 76 2001-000429 C RESISTOR
DR 77 2001-000522 C RESISTOR
DR 78 2001-000734 C RESISTOR
DR 79 2001-000449 C RESISTOR
DR 80 2001-000449 C RESISTOR
DR 81 2001-000449 C RESISTOR
DR 82 2001-000449 C RESISTOR
DR 83 2001-000449 C RESISTOR
DR 84 2001-000449 C RESISTOR
DR 85 2001-000786 C RESISTOR
DR 86 2001-000773 C RESISTOR
DR 87 2001-000525 C RESISTOR
DR 88 2001-000449 C RESISTOR
DR 89 2001-000008 C RESISTOR
DR 90 2001-000591 C RESISTOR
DR 91 2001-000008 C RESISTOR
DR 92 2001-000591 C RESISTOR
DR 93 2001-000591 C RESISTOR
DR 94 2001-000864 C RESISTOR
DR 95 2001-000449 C RESISTOR
DR 96 2001-000864 C RESISTOR
DR 97 2001-000563 C RESISTOR
DR 98 2001-000449 C RESISTOR
DR 99 2001-000563 C RESISTOR
DR100 2001-000258 C RESISTOR
DR101 2001-000281 C RESISTOR
DR102 2001-000281 C RESISTOR
DR120 2001-000449 C RESISTOR
DR200 2001-001140 C RESISTOR
DR201 2001-001153 C RESISTOR
DR203 2001-000522 C RESISTOR
DVR 1 2103-000248 SEMI F.VR.
DVR 2 2103-000248 SEMI F.VR.
DVR 3 2103-000492 SEMI F.VR.
DW 1 3711-003111 CONNECTOR
DW 2 3711-003107 CONNECTOR
DW 3 3711-003107 CONNECTOR
EC 1 2401-001912 E CAPACITOR
EC 2 2401-001912 E CAPACITOR
EC 3 2202-000797 C CAPACITOR
EC 4 2202-000809 C CAPACITOR
EC 5 2401-001889 E CAPACITOR
EC 6 2401-000907 E CAPACITOR
Item
Parts number Parts name Area
Remarks
A
